183-025 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB RCPT 25POS R/A SLDR
| Part | Color | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Contact Finish Thickness | Contact Finish | Number of Positions | Flange Feature | Current Rating (Amps) | Number of Rows [custom] | Mounting Type | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Connector Style | Material Flammability Rating | Termination | Backset Spacing | Backset Spacing | Connector Type | Features | Contact Material | Flange Feature | Shell Material, Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Black | Polyester Glass Filled | -55 C | 105 ░C | Signal | Flash | Gold | 25 | Housing/Shell (Unthreaded) | 5 A | 2 | Panel Mount Right Angle Through Hole | B DB | 3 | D-Sub | UL94 V-0 | Solder | 0.59 in | 14.99 mm | Receptacle Female Sockets | ||||
 NorComp Inc. | Black | Polyester Glass Filled | -55 C | 105 ░C | Signal | Flash | Gold | 25 | Housing/Shell (Unthreaded) | 5 A | 2 | Panel Mount Right Angle Through Hole | B DB | 3 | D-Sub | UL94 V-0 | Solder | 0.59 in | 14.99 mm | Receptacle Female Sockets | Ground Strap | |||
 NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Signal | Flash | Gold | 25 | Housing/Shell | 5 A | 2 | Panel Mount Right Angle Through Hole | B DB | 3 | D-Sub | UL94 V-0 | Solder | 0.59 in | 14.99 mm | Plug Male Pins | Board Lock Grounding Indents | Brass | 4-40 | Nickel Plated Steel |
 NorComp Inc. | Black | Polyester Glass Filled | -55 C | 105 ░C | Signal | Flash | Gold | 25 | Housing/Shell (Unthreaded) | 5 A | 2 | Panel Mount Right Angle Through Hole | B DB | 3 | D-Sub | UL94 V-0 | Solder | 0.59 in | 14.99 mm | Plug Male Pins | Ground Strap Grounding Indents | |||
NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Signal | Flash | Gold | 25 | Housing/Shell (Unthreaded) | 5 A | 2 | Panel Mount Right Angle Through Hole | B DB | 3 | D-Sub | UL94 V-0 | Solder | 0.59 in | 14.99 mm | Plug Male Pins | Grounding Indents | Brass | Nickel Plated Steel | |
NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Signal | Flash | Gold | 25 | Housing/Shell | 5 A | 2 | Panel Mount Right Angle Through Hole | B DB | 3 | D-Sub | UL94 V-0 | Solder | 0.59 in | 14.99 mm | Plug Male Pins | Grounding Indents | Brass | 4-40 | Nickel Plated Steel |
NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Signal | Flash | Gold | 25 | Housing/Shell | 5 A | 2 | Panel Mount Right Angle Through Hole | B DB | 3 | D-Sub | UL94 V-0 | Solder | 0.59 in | 14.99 mm | Plug Male Pins | Grounding Indents | Brass | 4-40 | Nickel Plated Steel |
 NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Signal | Flash | Gold | 25 | Housing/Shell | 5 A | 2 | Panel Mount Right Angle Through Hole | B DB | 3 | D-Sub | UL94 V-0 | Solder | 0.59 in | 14.99 mm | Receptacle Female Sockets | Ground Strap | Brass | 4-40 | Nickel Plated Steel |
NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Signal | Flash | Gold | 25 | Housing/Shell | 5 A | 2 | Panel Mount Right Angle Through Hole | B DB | 3 | D-Sub | UL94 V-0 | Solder | 0.59 in | 14.99 mm | Receptacle Female Sockets | Board Lock | Brass | 4-40 | Nickel Plated Steel |
 NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Signal | Flash | Gold | 25 | 4-40 Mating Side Female Screwlock | 5 A | 2 | Panel Mount Right Angle Through Hole | B DB | 3 | D-Sub | UL94 V-0 | Solder | 0.59 in | 14.99 mm | Plug Male Pins | Board Lock Grounding Indents | Brass | Nickel Plated Steel |
