818 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN IC DIP SOCKET 18POS GOLD
| Part | Current Rating (Amps) | Contact Resistance | Material Flammability Rating | Termination Post Length | Termination Post Length | Pitch - Mating | Pitch - Mating | Contact Finish - Post | Operating Temperature [Min] | Operating Temperature [Max] | Features | Type | Type | Type | Housing Material | Termination | Contact Finish - Mating | Contact Material - Post [custom] | Pitch - Post | Pitch - Post | Number of Positions or Pins (Grid) | Mounting Type | Contact Material - Mating | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 3 A | 10 mOhm | UL94 V-0 | 0.125 in | 3.18 mm | 0.1 " | 2.54 mm | Tin-Lead | -55 C | 105 ░C | Open Frame | 7.62 mm | 0.3 in | DIP | Polyester | Solder | Gold | Copper Alloy | 0.1 in | 2.54 mm | 18 | Through Hole | Copper Alloy | ||
 TE Connectivity AMP Connectors | 3 A | 10 mOhm | UL94 V-0 | 0.125 in | 3.18 mm | 0.1 " | 2.54 mm | -55 C | 105 ░C | Open Frame | 7.62 mm | 0.3 in | DIP | Polyester | Solder | Tin-Lead | 0.1 in | 2.54 mm | 18 | Through Hole | Copper Alloy | 2.03 µm | 80 µin | ||
TE Connectivity AMP Connectors | 3 A | 10 mOhm | UL94 V-0 | 0.125 in | 3.18 mm | 0.1 " | 2.54 mm | -55 C | 105 ░C | Open Frame | 7.62 mm | 0.3 in | DIP | Polyester | Solder | Gold | 0.1 in | 2.54 mm | 18 | Through Hole | Copper Alloy |
