BG95 Series
Manufacturer: Quectel
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
BG95-M3-TE-A
| Part | Contents | Utilized IC / Part | Type | Frequency | Frequency | Protocol | Package / Case | Mounting Type | Data Rate | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Serial Interfaces | Antenna Type | Power - Output | Operating Temperature (Max) | Operating Temperature (Min) | Current - Receiving | RF Family/Standard |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Quectel | Board | BG95 | Cellular | 1.8 GHz 1.9 GHz 850 MHz 900 MHz | 1.8GHz 1.9GHz 850MHz 900MHz | |||||||||||||
 Quectel | Board | BG95 | Cellular | BeiDou Galileo GLONASS GNSS GPS LTE | Module | Surface Mount | 1.119 Mbps | 2.6 V | 4.8 V | GPIO I2C PCM UART USB | Antenna Not Included | 21 dBm | 75 °C | -35 °C | 20 mA | Cellular Navigation | ||
 Quectel | Board | BG95 | Cellular | BeiDou Galileo GLONASS GNSS GPS LTE | Module | Surface Mount | 1.119 Mbps | 2.6 V | 4.8 V | GPIO I2C PCM UART USB | Antenna Not Included | 21 dBm | 75 °C | -35 °C | 21.2 mA | Cellular Navigation | ||
 Quectel | MDM9205-0 | Module | Surface Mount | |||||||||||||||
Quectel | MDM9205-2 | Module | Surface Mount | |||||||||||||||
Quectel | MDM9205-0 | 1.8 GHz 1.9 GHz 850 MHz 900 MHz | 1.8GHz 1.9GHz 850MHz 900MHz | BeiDou EGDE Galileo GLONASS GNSS GPS GSM LTE | Module | Surface Mount | 1.119 Mbps | 3.3 V | 4.3 V | GPIO I2C PCM UART USB | Antenna Not Included | 32 dBm | 75 °C | -35 °C | Cellular Navigation | |||
Quectel | MDM9205-0 | Module | Surface Mount | |||||||||||||||
Quectel | BeiDou Galileo GLONASS GNSS GPS LTE | Module | Surface Mount | 158.5 kbps | 2.6 V | 4.8 V | GPIO I2C PCM UART USB | Antenna Not Included | 21 dBm | 75 °C | -35 °C | 20 mA | Cellular Navigation | |||||
Quectel | Board | BG95 | Cellular | BeiDou Galileo GLONASS GNSS GPS LTE | Module | Surface Mount | 158.5 kbps | 2.6 V | 4.8 V | GPIO I2C PCM UART USB | Antenna Not Included | 21 dBm | 75 °C | -35 °C | 20 mA | Cellular Navigation | ||
 Quectel | MDM9205-0 | 1.8 GHz 1.9 GHz 850 MHz 900 MHz | 1.8GHz 1.9GHz 850MHz 900MHz | BeiDou EGDE Galileo GLONASS GNSS GPS GSM LTE | Module | mini PCIe | 1.119 Mbps | 3.3 V | 4.3 V | GPIO I2C PCM UART USB | Antenna Not Included | 21 dBm | 75 °C | -35 °C | 18.9 mA | Cellular Navigation |
