857-064 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 64POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Number of Positions/Bay/Row | Contact Finish | Termination | Mounting Type | Pitch | Pitch | Gender | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Contact Material | Read Out | Color | Flange Feature | Features | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 32 | Tin | Solder | Right Angle Through Hole | 3.96 mm | 0.156 in | Female | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Single | Black | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 32 | Tin | Solder | Board Edge Straddle Mount | 3.96 mm | 0.156 in | Female | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Dual | Black | Flush Mount M3 Threaded Insert Top Opening | Card Extender | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 32 | Gold | Solder | Board Edge Straddle Mount | 3.96 mm | 0.156 in | Female | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Dual | Black | Card Extender | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 32 | Tin | Solder | Through Hole | 3.96 mm | 0.156 in | Female | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Dual | Black | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 32 | Tin | Solder | Right Angle Through Hole | 3.96 mm | 0.156 in | Female | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Single | Black | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 32 | Tin | Solder Eyelet(s) | Through Hole | 3.96 mm | 0.156 in | Female | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Dual | Black | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 32 | Gold | Solder | Right Angle Through Hole | 3.96 mm | 0.156 in | Female | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Single | Black | Floating Bobbin Flush Mount | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 32 | Gold | Solder | Board Edge Straddle Mount | 3.96 mm | 0.156 in | Female | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Dual | Black | Flush Mount M3 Threaded Insert Top Opening | Card Extender | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 32 | Gold | Wire Wrap | Through Hole | 3.96 mm | 0.156 in | Female | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Dual | Black | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 32 | Tin | Wire Wrap | Through Hole | 3.96 mm | 0.156 in | Female | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Dual | Black | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm |
