282962 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
TERMI-BLOK HEADER ASSY90 4P.
| Part | Contact Tail Length | Contact Tail Length | Positions Per Level | Mounting Type | Number of Levels | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - UL | Pitch [x] | Pitch [x] | Color | Termination Style | Header Orientation | Number of Positions | Contact Mating Finish | Material Flammability Rating | Type | Insulation Height | Insulation Height | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | 3.5 mm | 0.138 in | 4 | Through Hole | 1 | -40 °C | 110 °C | 300 V | 0.295 in | 7.5 mm | Green | Solder | 90° Right Angle | 4 | Tin | UL94 V-0 | Header Male Pins Shrouded (4 Side) | 8.36 mm | 0.329 in | Copper Alloy |
 TE Connectivity Raychem Cable Protection | 3.5 mm | 0.138 in | 2 | Through Hole | 1 | -40 °C | 110 °C | 300 V | 0.295 in | 7.5 mm | Green | Solder | 90° Right Angle | 2 | Tin | UL94 V-0 | Header Male Pins Shrouded (4 Side) | 8.36 mm | 0.329 in | Copper Alloy |
