MULTI-BEAM HD Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
MULTI-BEAM HD R/A PLUG 2P+15S EXTEND PLA
| Part | Material Flammability Rating | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Color | Number of Positions | Mounting Type | Contact Finish | Connector Style | Number of Positions Loaded | Contact Layout, Typical | Connector Type | Features | Contact Layout, Typical [custom] | Contact Layout, Typical [custom] | Number of Positions [custom] | Contact Layout, Typical [custom] | Contact Layout, Typical [custom] | Current Rating (Amps) | Pitch [x] | Pitch [x] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | ||||||||||||||||||||||||
 TE Connectivity AMP Connectors | UL94 V-0 | 125 °C | -40 C | Press-Fit | Black | 2 | Through Hole | Gold Gold-Palladium | Multi-Beam | All | 2 Power | Receptacle Female Blade Sockets | ||||||||||||
TE Connectivity AMP Connectors | Press-Fit | Black | 36 | Right Angle Through Hole | Gold Gold-Palladium | Multi-Beam | All | Blade Sockets Female Sockets Receptacle | Guide Pin | 30 | 6 | |||||||||||||
 TE Connectivity AMP Connectors | Press-Fit | Black | 30 | Board Edge Right Angle Through Hole | Gold Gold-Palladium | Multi-Beam | All | Plug Male Pins and Blades | Board Guide | 27 | 3 | |||||||||||||
TE Connectivity AMP Connectors | ||||||||||||||||||||||||
 TE Connectivity AMP Connectors | Press-Fit | Black | Right Angle Through Hole | Gold Gold-Palladium | Multi-Beam | All | Blade Sockets Female Sockets Receptacle | Board Guide | 34 | 30 Signal | 4 Power | |||||||||||||
 TE Connectivity AMP Connectors | UL94 V-0 | 125 °C | -40 C | Press-Fit | Black | 42 | Through Hole | Gold Gold-Palladium | Multi-Beam | All | Blade Sockets Female Sockets Receptacle | Board Guide Guide Pin | 30 | 12 | 1116 A | 0.079 in | 2 mm | 3 µin | 0.076 Ám | 5 | ||||
 TE Connectivity AMP Connectors | Press-Fit | Black | 30 | Through Hole | Gold Gold-Palladium | Multi-Beam | All | Blade Sockets Female Sockets Receptacle | Board Guide Guide Pin | 27 | 3 | 3 µin | 0.076 Ám | |||||||||||
 TE Connectivity AMP Connectors | ||||||||||||||||||||||||
 TE Connectivity AMP Connectors | Solder | Black | 24 | Board Edge Right Angle Through Hole | Gold Gold-Palladium | Multi-Beam | All | Plug Male Pins and Blades | Board Guide | 20 | 4 | 5 |
