794635 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HEADER SMD 2POS

Part	Applications	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Style	Current Rating (Amps)	Number of Rows [custom]	Row Spacing - Mating	Row Spacing - Mating	Contact Shape	Contact Type	Material Flammability Rating	Contact Finish - Mating	Voltage Rating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Shrouding	Connector Type	Number of Positions Loaded	Insulation Height [z]	Insulation Height [z]	Mounting Type	Contact Finish - Post	Contact Material	Features	Termination	Fastening Type	Insulation Material	Number of Positions	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Color	Pitch - Mating	Pitch - Mating
TE Connectivity AMP Connectors 3-794635-2	General Purpose Industrial Lighting	2.54 µm	100 µin	Board to Cable/Wire	Varies by Wire Gauge	2	0.118 in	3 mm	Square	Male Pin	UL94 V-0	Gold	250 V	0.76 Ám	30 Áin	Shrouded - 4 Wall	Header	All	9.25 mm	0.364 in	Surface Mount	Tin	Brass	Board Lock Pick and Place	Solder	Locking Ramp	Nylon Polyamide (PA)	2	-40 C	105 ░C	Black
TE Connectivity AMP Connectors 3-794635-4	General Purpose Industrial Lighting	2.54 µm	100 µin	Board to Cable/Wire	Varies by Wire Gauge	2	0.118 in	3 mm	Square	Male Pin	UL94 V-0	Gold	250 V	0.76 Ám	30 Áin	Shrouded - 4 Wall	Header	All	9.25 mm	0.364 in	Surface Mount	Tin	Brass	Board Lock Pick and Place	Solder	Locking Ramp	Nylon Polyamide (PA)	4	-40 C	105 ░C	Black	3 mm	0.118 in
TE Connectivity AMP Connectors 5-794635-4	General Purpose Industrial Lighting	2.54 µm	100 µin	Board to Cable/Wire	Varies by Wire Gauge	2	0.118 in	3 mm	Square	Male Pin	UL94 V-0	Gold	250 V	0.76 Ám	30 Áin	Shrouded - 4 Wall	Header	All	9.25 mm	0.364 in	Surface Mount	Tin	Brass	Board Lock Pick and Place	Solder	Locking Ramp	Nylon Polyamide (PA)	24	-40 C	105 ░C	Black	3 mm	0.118 in
TE Connectivity AMP Connectors 794635-6	General Purpose Industrial Lighting	2.54 µm	100 µin	Board to Cable/Wire	Varies by Wire Gauge	2	0.118 in	3 mm	Square	Male Pin	UL94 V-0	Gold	250 V	0.76 Ám	30 Áin	Shrouded - 4 Wall	Header	All	9.25 mm	0.364 in	Surface Mount	Tin-Lead	Brass	Board Lock Pick and Place	Solder	Locking Ramp	Nylon Polyamide (PA)	6	-40 C	105 ░C	Black	3 mm	0.118 in
TE Connectivity AMP Connectors 4-794635-2	General Purpose Industrial Lighting	2.54 µm	100 µin	Board to Cable/Wire	Varies by Wire Gauge	2	0.118 in	3 mm	Square	Male Pin	UL94 V-0	Gold	250 V	0.76 Ám	30 Áin	Shrouded - 4 Wall	Header	All	9.25 mm	0.364 in	Surface Mount	Tin	Brass	Board Lock Pick and Place	Solder	Locking Ramp	Nylon Polyamide (PA)	12	-40 C	105 ░C	Black	3 mm	0.118 in
TE Connectivity AMP Connectors 1-794635-0	General Purpose Industrial Lighting	2.54 µm	100 µin	Board to Cable/Wire	Varies by Wire Gauge	2	0.118 in	3 mm	Square	Male Pin	UL94 V-0	Gold	250 V	0.76 Ám	30 Áin	Shrouded - 4 Wall	Header	All	9.25 mm	0.364 in	Surface Mount	Tin-Lead	Brass	Board Lock Pick and Place	Solder	Locking Ramp	Nylon Polyamide (PA)	10	-40 C	105 ░C	Black	3 mm	0.118 in
TE Connectivity AMP Connectors 2-794635-0	General Purpose Industrial Lighting	2.54 µm	100 µin	Board to Cable/Wire	Varies by Wire Gauge	2	0.118 in	3 mm	Square	Male Pin	UL94 V-0	Gold	250 V	0.76 Ám	30 Áin	Shrouded - 4 Wall	Header	All	9.25 mm	0.364 in	Surface Mount	Tin-Lead	Brass	Board Lock Pick and Place	Solder	Locking Ramp	Nylon Polyamide (PA)	20	-40 C	105 ░C	Black	3 mm	0.118 in
