337-041 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 41POS 0.156
| Part | Termination Rows | Material - Insulation | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Pitch | Pitch | Mounting Type | Termination | Gender | Number of Rows | Contact Type | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Features | Contact Finish | Number of Positions/Bay/Row | Card Type | Read Out | Color | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 41 | 3.96 mm | 0.156 in | Through Hole | Solder Eyelet(s) | Female | 1 | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Card Guides | Gold | 41 | Non Specified - Single Edge | Single | Green | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 41 | 3.96 mm | 0.156 in | Through Hole | Solder | Female | 1 | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Gold | 41 | Non Specified - Single Edge | Single | Green | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 41 | 3.96 mm | 0.156 in | Through Hole | Wire Wrap | Female | 1 | Cantilever | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Gold | 41 | Non Specified - Single Edge | Single | Green | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 41 | 3.96 mm | 0.156 in | Through Hole | Wire Wrap | Female | 1 | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Gold | 41 | Non Specified - Single Edge | Single | Green | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 41 | 3.96 mm | 0.156 in | Right Angle Through Hole | Wire Wrap | Female | 1 | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Gold | 41 | Non Specified - Single Edge | Single | Green | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 41 | 3.96 mm | 0.156 in | Through Hole | Solder | Female | 1 | Cantilever | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Gold | 41 | Non Specified - Single Edge | Single | Green | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 41 | 3.96 mm | 0.156 in | Through Hole | Solder | Female | 1 | Cantilever | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Gold | 41 | Non Specified - Single Edge | Single | Green | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 41 | 3.96 mm | 0.156 in | Right Angle Through Hole | Wire Wrap | Female | 1 | Cantilever | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Gold | 41 | Non Specified - Single Edge | Single | Green | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 41 | 3.96 mm | 0.156 in | Through Hole | Wire Wrap | Female | 1 | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Gold | 41 | Non Specified - Single Edge | Single | Green | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 41 | 3.96 mm | 0.156 in | Through Hole | Solder Eyelet(s) | Female | 1 | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Gold | 41 | Non Specified - Single Edge | Single | Green | 0.128 " | 3.25 mm |
