GLAA2 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH SNAP ACTION DPDT 6A 120V
| Part | Features | Current Rating (Amps) | Ingress Protection | Actuator Type | Mechanical Life | Operating Force | Termination Style | Operating Position | Pretravel | Operating Temperature [Min] | Operating Temperature [Max] | Circuit | Mounting Type | Switch Function | Voltage Rating - AC | Voltage Rating - DC | Overtravel | Differential Travel |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Honeywell Sensing and Productivity Solutions | Center Neutral | 6 A 550 mA | IP67 - Dust Tight Waterproof | Roller Side Rotary | 15000000 Cycles | 33 gfm | Screw Terminal | 16 ° | 16 ° | -25 °C | 85 °C | DPDT | Chassis Mount | Mom-Off-Mom | 120 V | 125 VDC | ||
Honeywell Sensing and Productivity Solutions | Sequence Action | 6 A 550 mA | IP67 - Dust Tight Waterproof | Roller Side Rotary | 15000000 Cycles | 33 gfm | Cable Leads | 26 ° | 26 ° | -25 °C | 85 °C | DPDT | Chassis Mount | On-Mom | 120 V | 125 VDC | 59 ° | 12 ° |
 Honeywell Sensing and Productivity Solutions | Steel Roller | 6 A 550 mA | IP67 - Dust Tight Waterproof | Roller Side Rotary | 15000000 Cycles | 33 gfm | Screw Terminal | 26 ° | 26 ° | -25 °C | 85 °C | DPDT | Chassis Mount | On-Mom | 120 V | 125 VDC | 59 ° | 12 ° |
 Honeywell Sensing and Productivity Solutions | Nylon Roller | 6 A 550 mA | IP67 - Dust Tight Waterproof | Side Rotary Adjustable Roller | 15000000 Cycles | 33 gfm | Screw Terminal | 26 ° | 26 ° | -25 °C | 85 °C | DPDT | Chassis Mount | On-Mom | 120 V | 125 VDC | 59 ° | 12 ° |
