0566-2 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN PIN RCPT

Part	Operating Temperature [Min]	Operating Temperature [Max]	Length - Overall [x]	Length - Overall [x]	Termination	Contact Finish	Pin Hole Diameter [diameter]	Pin Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Contact Finish Thickness	Contact Finish Thickness	Socket Depth	Socket Depth	Tail Type	Contact Material	Flange Diameter	Flange Diameter	Accepts Pin Diameter [Min]	Accepts Pin Diameter [Max]	Accepts Pin Diameter [Min]	Accepts Pin Diameter [Max]
Mill-Max Manufacturing Corp. 0566-2-15-80-21-27-10-0	-55 C	125 °C	3.51 mm	0.138 in	Solder	Gold	0.031 in	0.79 mm	0.039 in	0.99 mm	30 Áin	0.76 Ám	0.083 in	2.11 mm	No Tail	Beryllium Copper	0.058 in	1.47 mm	0.38 mm	0.022 in	0.015 "	0.56 mm
Mill-Max Manufacturing Corp. 0566-2-15-80-21-14-10-0	-55 C	125 °C	3.51 mm	0.138 in	Solder	Gold	0.031 in	0.79 mm	0.039 in	0.99 mm	10 Áin	0.25 Ám	0.083 in	2.11 mm	No Tail	Beryllium Copper	0.058 in	1.47 mm	0.38 mm	0.022 in	0.015 "	0.56 mm
Mill-Max Manufacturing Corp. 0566-2-15-80-21-84-10-0	-55 C	125 °C	3.51 mm	0.138 in	Solder	Tin	0.031 in	0.79 mm	0.039 in	0.99 mm	100 µin	2.54 µm	0.083 in	2.11 mm	No Tail	Beryllium Copper	0.058 in	1.47 mm	0.38 mm	0.022 in	0.015 "	0.56 mm
Mill-Max Manufacturing Corp. 0566-2-15-01-21-14-10-0	-55 C	125 °C	3.51 mm	0.138 in	Solder	Gold	0.031 in	0.79 mm	0.039 in	0.99 mm	10 Áin	0.25 Ám	0.138 in	3.51 mm	No Tail	Beryllium Copper	0.058 in	1.47 mm	0.38 mm	0.022 in	0.015 "	0.56 mm
Mill-Max Manufacturing Corp. 0566-2-15-15-21-14-10-0	-55 C	125 °C	3.51 mm	0.138 in	Solder	Gold	0.031 in	0.79 mm	0.039 in	0.99 mm	10 Áin	0.25 Ám	0.083 in	2.11 mm	No Tail	Beryllium Copper	0.058 in	1.47 mm	0.38 mm	0.022 in	0.015 "	0.56 mm
Mill-Max Manufacturing Corp. 0566-2-15-15-21-27-10-0	-55 C	125 °C	3.51 mm	0.138 in	Solder	Gold	0.031 in	0.79 mm	0.039 in	0.99 mm	30 Áin	0.76 Ám	0.138 in	3.51 mm	No Tail	Beryllium Copper	0.058 in	1.47 mm	0.38 mm	0.022 in	0.015 "	0.56 mm
Mill-Max Manufacturing Corp. 0566-2-15-01-21-02-10-0	-55 C	125 °C	3.51 mm	0.138 in	Solder	Tin-Lead	0.031 in	0.79 mm	0.039 in	0.99 mm	100 µin	2.54 µm	0.138 in	3.51 mm	No Tail	Beryllium Copper	0.058 in	1.47 mm	0.38 mm	0.022 in	0.015 "	0.56 mm
Mill-Max Manufacturing Corp. 0566-2-15-01-21-27-10-0	-55 C	125 °C	3.51 mm	0.138 in	Solder	Gold	0.031 in	0.79 mm	0.039 in	0.99 mm	30 Áin	0.76 Ám	0.138 in	3.51 mm	No Tail	Beryllium Copper	0.058 in	1.47 mm	0.38 mm	0.022 in	0.015 "	0.56 mm
