SX1277 Series
Manufacturer: Semtech Corporation
Beta
⌘K
IC RF TXRX 802.15.4 28QFN
| Part | Current - Transmitting [Min] [x] | Current - Transmitting [Max] [x] | Serial Interfaces | Modulation | Data Rate (Max) | Sensitivity | Package / Case | GPIO | Type | Operating Temperature [Max] | Operating Temperature [Min] | RF Family/Standard | Supplier Device Package | Voltage - Supply [Min] | Voltage - Supply [Max] | Protocol | Mounting Type | Frequency [Max] | Frequency [Min] | Power - Output | Current - Receiving [Max] | Current - Receiving [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Semtech Corporation | 20 mA | 120 mA | SPI | FSK GFSK GMSK MSK OOK | 300 kbps | -148 dBm | 28-VQFN Exposed Pad | 6 | TxRx Only | 85 °C | -40 C | 802.15.4 | 28-QFN (6x6) | 1.8 V | 3.7 V | LoRa™ | Surface Mount | 1.02 GHz | 137 MHz | 20 dBm | 12 mA | 10.8 mA |
