P35-5 Series

Manufacturer: Polytron

Catalog

AC/DC CONVERTER +/-5V

Part	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1	Voltage - Output 2	Type	Current - Output 1	Voltage - Input [Min]	Voltage - Input [Max]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Approval Agency	Current - Output 2	Mounting Type	Voltage - Isolation	Applications	Number of Outputs	Line Regulation	Load Regulation	Current - Output (Max) [Max]	Package / Case	Features
Polytron P35-5T/MHIA	71 °C	-25 °C	5 V	-5 V	Enclosed	300 mA	105 VAC	125 VAC	4.1 "	39.6 mm	63.5 mm	1.56 "	104.1 mm	2.5 "	CE cURus	300 mA	Chassis Mount	4000 V	Medical	2
Polytron P35-5AX	71 °C	-25 °C	5 V		Enclosed		115 VAC	220 VAC	3.5 "	39.6 mm	63.5 mm	1.56 "	88.9 mm	2.5 "	CE cURus UL		Through Hole		ITE (Commercial)	2	0.02 %	0.05 %	0.3 A	7-DIP Module	SCP
Polytron P35-5-04	71 °C	-25 °C	5 V		Enclosed		105 VAC	125 VAC	3.5 "	39.6 mm	63.5 mm	1.56 "	88.9 mm	2.5 "	CE cURus UL		Through Hole		ITE (Commercial)	2	0.02 %	0.05 %	0.3 A	7-DIP Module 5 Leads	SCP
Polytron P35-5AX/MHIA	71 °C	-25 °C	5 V		Enclosed		115 VAC	220 VAC	3.5 "	39.6 mm	63.5 mm	1.56 "	88.9 mm	2.5 "	CE cURus		Through Hole		Medical	2	0.02 %	0.05 %	0.3 A	7-DIP Module 5 Leads
Polytron P35-5AX/22	71 °C	-25 °C	5 V		Enclosed		105 VAC	125 VAC	3.5 "	39.6 mm	63.5 mm	1.56 "	88.9 mm	2.5 "	CE cURus		Through Hole		ITE (Commercial)	2	0.02 %	0.05 %	0.3 A	7-DIP Module 5 Leads
Polytron P35-5W/MHIA	85 °C	-40 C	5 V		Enclosed		105 VAC	125 VAC	3.5 "	39.6 mm	63.5 mm	1.56 "	88.9 mm	2.5 "	CE cURus		Through Hole		Medical	2	0.02 %	0.05 %	0.3 A	7-DIP Module 5 Leads
Polytron P35-5QX	71 °C	-25 °C	5 V		Enclosed		100 VAC	125 VAC	3.5 "	39.6 mm	63.5 mm	1.56 "	88.9 mm	2.5 "	CE cURus UL		Through Hole		ITE (Commercial)	2	0.02 %	0.05 %	0.3 A	7-DIP Module 5 Leads	SCP
