8503 Series
Manufacturer: Belden Inc.
Beta
⌘K
HOOK-UP STRND 22AWG GRAY 100'
| Part | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Cable Type | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Wire Gauge | Qualification | Voltage | Conductor Material | Length [x] | Length [x] | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Material | Jacket Color | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 0.25 mm | 0.01 in | Hook-Up | 0.05 " | 1.27 mm | -40 C | 105 ░C | 22 AWG | MIL-W-16878/1 Type B | 600 V | Copper Tinned | 100 ft | 30.5 m | 30 AWG | 7 | Poly-Vinyl Chloride (PVC) | Gray | ||
 Belden Inc. | 0.25 mm | 0.01 in | Hook-Up | 0.05 " | 1.27 mm | -40 C | 105 ░C | 22 AWG | MIL-W-16878/1 Type B | 600 V | Copper Tinned | 30 AWG | 7 | Poly-Vinyl Chloride (PVC) | Blue | 304.8 m | 1000 ft | ||
 Belden Inc. | 0.25 mm | 0.01 in | Hook-Up | 0.05 " | 1.27 mm | -40 C | 105 ░C | 22 AWG | MIL-W-16878/1 Type B | 600 V | Copper Tinned | 100 ft | 30.5 m | 30 AWG | 7 | Poly-Vinyl Chloride (PVC) | Green | ||
 Belden Inc. | 0.25 mm | 0.01 in | Hook-Up | 0.05 " | 1.27 mm | -40 C | 105 ░C | 22 AWG | MIL-W-16878/1 Type B | 600 V | Copper Tinned | 30 AWG | 7 | Poly-Vinyl Chloride (PVC) | Gray | 304.8 m | 1000 ft | ||
 Belden Inc. | 0.25 mm | 0.01 in | Hook-Up | 0.05 " | 1.27 mm | -40 C | 105 ░C | 22 AWG | MIL-W-16878/1 Type B | 600 V | Copper Tinned | 30 AWG | 7 | Poly-Vinyl Chloride (PVC) | Green | 304.8 m | 1000 ft | ||
 Belden Inc. | 0.25 mm | 0.01 in | Hook-Up | 0.05 " | 1.27 mm | -40 C | 105 ░C | 22 AWG | MIL-W-16878/1 Type B | 600 V | Copper Tinned | 30 AWG | 7 | Poly-Vinyl Chloride (PVC) | White Blue Stripe | 304.8 m | 1000 ft | ||
 Belden Inc. | 0.25 mm | 0.01 in | Hook-Up | 0.05 " | 1.27 mm | -40 C | 105 ░C | 22 AWG | MIL-W-16878/1 Type B | 600 V | Copper Tinned | 100 ft | 30.5 m | 30 AWG | 7 | Poly-Vinyl Chloride (PVC) | White | ||
 Belden Inc. | 0.25 mm | 0.01 in | Hook-Up | 0.05 " | 1.27 mm | -40 C | 105 ░C | 22 AWG | MIL-W-16878/1 Type B | 600 V | Copper Tinned | 30 AWG | 7 | Poly-Vinyl Chloride (PVC) | Brown | 304.8 m | 1000 ft | ||
 Belden Inc. | 0.25 mm | 0.01 in | Hook-Up | 0.05 " | 1.27 mm | -40 C | 105 ░C | 22 AWG | MIL-W-16878/1 Type B | 600 V | Copper Tinned | 30 AWG | 7 | Poly-Vinyl Chloride (PVC) | Yellow | 304.8 m | 1000 ft | ||
 Belden Inc. | 0.25 mm | 0.01 in | Hook-Up | 0.05 " | 1.27 mm | -40 C | 105 ░C | 22 AWG | MIL-W-16878/1 Type B | 600 V | Copper Tinned | 100 ft | 30.5 m | 30 AWG | 7 | Poly-Vinyl Chloride (PVC) | Violet |
