BAT43 Series

Catalog

DIODE SCHOTTKY 30V 200MA SOD523F

Part	Voltage - Forward (Vf) (Max) @ If [Max]	Speed	Speed	Operating Temperature - Junction [Min]	Operating Temperature - Junction [Max]	Current - Average Rectified (Io)	Current - Reverse Leakage @ Vr	Capacitance @ Vr, F	Mounting Type	Reverse Recovery Time (trr)	Package / Case	Supplier Device Package	Technology	Voltage - DC Reverse (Vr) (Max) [Max]	Voltage - Forward (Vf) (Max) @ If
Taiwan Semiconductor Corporation BAT43X RKG	1 V	200 mA	Any Speed	-55 °C	150 °C	200 mA	500 nA	10 pF	Surface Mount	5 ns	SC-79 SOD-523	SOD-523F	Schottky	30 V
Taiwan Semiconductor Corporation BAT43W RHG		200 mA	Any Speed	-55 °C	125 °C	200 mA	500 nA	10 pF	Surface Mount	5 ns	SOD-123	SOD-123	Schottky	30 V	650 mV
