MTJ-64 Series
Manufacturer: Adam Tech
Beta
⌘K
MODULAR JACK 6P4C
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Housing Material | Contact Finish Thickness | Shielding | Tab Direction | Contact Material | Number of Rows | Contact Finish | Mounting Type | Orientation | Number of Ports | Termination | Number of Positions/Contacts [y] | Number of Positions/Contacts [x] | LED Color | Features | Connector Type | Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | 125 °C | -40 C | Glass Filled Nylon Polyamide (PA) | Flash | Unshielded | Down | Phosphor Bronze | 1 | Gold | Surface Mount | 90 ° | 1 | Solder | 4 | 6 | Does Not Contain LED | Solder Retention | Jack | |
 Adam Tech | 85 °C | -40 C | Polybutylene Terephthalate (PBT) | Flash | Unshielded | Down | Phosphor Bronze | 1 | Gold | Through Hole | 90 ° | 1 | Solder | 4 | 6 | Does Not Contain LED | Board Lock | Jack | |
 Adam Tech | 85 °C | -40 C | Polybutylene Terephthalate (PBT) | Flash | Unshielded | Up | Phosphor Bronze | 1 | Gold | Through Hole | 90 ° | 1 | Solder | 4 | 6 | Does Not Contain LED | Board Lock | Jack | |
 Adam Tech | 70 °C | -40 C | Thermoplastic | Flash | Unshielded | Down | Phosphor Bronze | 1 | Gold | Surface Mount | 90 ° | 1 | Solder | 4 | 6 | Does Not Contain LED | Solder Retention | Jack | |
 Adam Tech | 125 °C | -40 C | Thermoplastic | Flash | Unshielded | User Selectable | Phosphor Bronze | 1 | Gold | Surface Mount | 1 | Solder | 4 | 6 | Does Not Contain LED | Solder Retention | Jack | Vertical | |
 Adam Tech | 125 °C | -40 C | Polybutylene Terephthalate (PBT) | Flash | Unshielded | Up | Phosphor Bronze | 1 | Gold | Through Hole | 90 ° | 1 | Solder | 4 | 6 | Does Not Contain LED | Board Lock | Jack | |
 Adam Tech | 85 °C | -40 C | Polybutylene Terephthalate (PBT) | Flash | Unshielded | Up | Phosphor Bronze | 1 | Gold | Through Hole | 90 ° | 1 | Solder | 4 | 6 | Does Not Contain LED | Board Lock | Jack | |
 Adam Tech | 85 °C | -40 C | Polybutylene Terephthalate (PBT) | Flash | Unshielded | Down | Phosphor Bronze | 1 | Gold | Through Hole | 90 ° | 1 | Solder | 4 | 6 | Does Not Contain LED | Board Lock | Jack | |
 Adam Tech | 85 °C | -40 C | Polybutylene Terephthalate (PBT) | Flash | Unshielded | Down | Phosphor Bronze | 1 | Gold | Through Hole | 90 ° | 1 | Solder | 4 | 6 | Does Not Contain LED | Board Lock | Jack |
