350-90 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN HEADER SMD 6POS 2.54MM
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Insulation Color | Shrouding | Mounting Type | Insulation Material | Contact Length - Mating | Contact Length - Mating | Contact Finish - Mating | Number of Positions | Termination | Contact Shape | Connector Type | Contact Finish - Post | Contact Material | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Type | Number of Positions Loaded | Number of Rows | Fastening Type | Pitch - Mating | Pitch - Mating | Overall Contact Length [x] | Overall Contact Length [x] | Contact Length - Post | Contact Length - Post | Number of Positions | Overall Contact Length | Overall Contact Length | Contact Length - Post [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | 200 µin | 5.08 µm | Black | Unshrouded | Surface Mount | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.142 in | 3.61 mm | Tin-Lead | 6 | Solder | Circular | Header | Tin-Lead | Brass Alloy | 5.08 µm | 200 µin | Male Pin | All | 1 | Push-Pull | 0.1 " | 2.54 mm | ||||||||
Mill-Max Manufacturing Corp. | 200 µin | 5.08 µm | Black | Unshrouded | Through Hole | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.166 in | 4.22 mm | Tin-Lead | 56 | Solder | Circular | Header | Tin-Lead | Brass Alloy | 5.08 µm | 200 µin | Male Pin | All | 1 | Push-Pull | 0.1 " | 2.54 mm | 0.477 in | 12.12 mm | 3.96 mm | 0.156 " | ||||
Mill-Max Manufacturing Corp. | 200 µin | 5.08 µm | Black | Unshrouded | Through Hole | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.166 in | 4.22 mm | Tin-Lead | Solder | Circular | Header | Tin-Lead | Brass Alloy | 5.08 µm | 200 µin | Male Pin | All | 1 | Push-Pull | 0.1 " | 2.54 mm | 0.477 in | 12.12 mm | 3.96 mm | 0.156 " | 47 | ||||
Mill-Max Manufacturing Corp. | 200 µin | 5.08 µm | Black | Unshrouded | Surface Mount | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.142 in | 3.61 mm | Tin-Lead | 28 | Solder | Circular | Header | Tin-Lead | Brass Alloy | 5.08 µm | 200 µin | Male Pin | All | 1 | Push-Pull | 0.1 " | 2.54 mm | ||||||||
Mill-Max Manufacturing Corp. | 200 µin | 5.08 µm | Black | Unshrouded | Through Hole | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.142 in | 3.61 mm | Tin-Lead | 48 | Solder | Circular | Header | Tin-Lead | Brass Alloy | 5.08 µm | 200 µin | Male Pin | All | 1 | Push-Pull | 0.1 " | 2.54 mm | 2.79 mm | 10 mm | 0.394 in | 0.11 in | ||||
Mill-Max Manufacturing Corp. | 200 µin | 5.08 µm | Black | Unshrouded | Surface Mount | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.142 in | 3.61 mm | Tin-Lead | 50 | Solder | Circular | Header | Tin-Lead | Brass Alloy | 5.08 µm | 200 µin | Male Pin | All | 1 | Push-Pull | 0.1 " | 2.54 mm | ||||||||
Mill-Max Manufacturing Corp. | 200 µin | 5.08 µm | Black | Unshrouded | Through Hole | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.166 in | 4.22 mm | Tin-Lead | 28 | Solder | Circular | Header | Tin-Lead | Brass Alloy | 5.08 µm | 200 µin | Male Pin | All | 1 | Push-Pull | 0.1 " | 2.54 mm | 0.477 in | 12.12 mm | 3.96 mm | 0.156 " | ||||
Mill-Max Manufacturing Corp. | 200 µin | 5.08 µm | Black | Unshrouded | Surface Mount | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.142 in | 3.61 mm | Tin-Lead | 37 | Solder | Circular | Header | Tin-Lead | Brass Alloy | 5.08 µm | 200 µin | Male Pin | All | 1 | Push-Pull | 0.1 " | 2.54 mm | ||||||||
Mill-Max Manufacturing Corp. | 200 µin | 5.08 µm | Black | Unshrouded | Through Hole | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.142 in | 3.61 mm | Tin-Lead | 50 | Solder | Circular | Header | Tin-Lead | Brass Alloy | 5.08 µm | 200 µin | Male Pin | All | 1 | Push-Pull | 0.1 " | 2.54 mm | 2.79 mm | 10 mm | 0.394 in | 0.11 in | ||||
 Mill-Max Manufacturing Corp. | 200 µin | 5.08 µm | Black | Unshrouded | Through Hole | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.142 in | 3.61 mm | Tin-Lead | 8 | Solder | Circular | Header | Tin-Lead | Brass Alloy | 5.08 µm | 200 µin | Male Pin | All | 1 | Push-Pull | 0.1 " | 2.54 mm | 2.79 mm | 10 mm | 0.394 in | 0.11 in |
