837-054 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 54POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Number of Positions | Number of Positions/Bay/Row | Mounting Type | Read Out | Color | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Number of Rows [custom] | Termination | Features | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Contact Material | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 54 | 27 | Board Edge Straddle Mount | Dual | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Solder | Card Extender | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 0.156 " | 3.96 mm | Female | 125 °C | -40 C | Non Specified - Dual Edge | Copper Alloy | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 54 | 27 | Through Hole | Dual | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Solder Eyelet(s) | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 0.116 " | 2.95 mm | Female | 125 °C | -40 C | Non Specified - Dual Edge | Copper Alloy | Floating Bobbin Top Mount Opening | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 54 | 27 | Right Angle Through Hole | Dual | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Solder | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 0.156 " | 3.96 mm | Female | 125 °C | -40 C | Non Specified - Dual Edge | Copper Alloy | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 54 | 27 | Right Angle Through Hole | Dual | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Solder | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 0.128 " | 3.25 mm | Female | 125 °C | -40 C | Non Specified - Dual Edge | Copper Alloy | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 54 | 27 | Through Hole | Dual | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Wire Wrap | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | Female | 125 °C | -40 C | Non Specified - Dual Edge | Copper Alloy | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 54 | 27 | Through Hole | Dual | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Wire Wrap | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 0.128 " | 3.25 mm | Female | 125 °C | -40 C | Non Specified - Dual Edge | Copper Alloy | Side Mount Opening Unthreaded | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 54 | 27 | Through Hole | Dual | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Solder | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | Female | 125 °C | -40 C | Non Specified - Dual Edge | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 54 | 27 | Board Edge Straddle Mount | Dual | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Solder | Card Extender | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 0.128 " | 3.25 mm | Female | 125 °C | -40 C | Non Specified - Dual Edge | Copper Alloy | Side Mount Opening Unthreaded |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 54 | 27 | Through Hole | Dual | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Solder | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 0.116 " | 2.95 mm | Female | 125 °C | -40 C | Non Specified - Dual Edge | Copper Alloy | Floating Bobbin Flush Mount | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 54 | 27 | Board Edge Straddle Mount | Dual | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Solder | Card Extender | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 0.116 " | 2.95 mm | Female | 125 °C | -40 C | Non Specified - Dual Edge | Copper Alloy | Floating Bobbin Top Mount Opening |
