5859/12 Series

Catalog

WIRE & WIRE MANAGMENT

Part	Cable Type	Qualification	Jacket Color	Conductor Material	Operating Temperature [Min]	Operating Temperature [Max]	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Wire Gauge	Length [x]	Length [x]	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length	Length
ALPHA WIRE 5859/12 RD005	Hook-Up	MIL-W-16878/4 Type E	Red	Copper Silver Coated	-60 °C	200 °C	600 V	2.89 mm	0.114 "	12 AWG	100 ft	30.5 m	19	25 AWG	Polytetrafluoroethylene (PTFE)	0.3 mm	0.012 in
ALPHA WIRE 5859/12 WH002	Hook-Up	MIL-W-16878/4 Type E	White	Copper Silver Coated	-60 °C	200 °C	600 V	2.89 mm	0.114 "	12 AWG			19	25 AWG	Polytetrafluoroethylene (PTFE)	0.3 mm	0.012 in	152.4 m	500 ft
ALPHA WIRE 5859/12 BK005	Hook-Up	MIL-W-16878/4 Type E	Black	Copper Silver Coated	-60 °C	200 °C	600 V	2.89 mm	0.114 "	12 AWG	100 ft	30.5 m	19	25 AWG	Polytetrafluoroethylene (PTFE)	0.3 mm	0.012 in
ALPHA WIRE 5859/12 BK002	Hook-Up	MIL-W-16878/4 Type E	Black	Copper Silver Coated	-60 °C	200 °C	600 V	2.89 mm	0.114 "	12 AWG			19	25 AWG	Polytetrafluoroethylene (PTFE)	0.3 mm	0.012 in	152.4 m	500 ft
ALPHA WIRE 5859/12 GR002	Hook-Up	MIL-W-16878/4 Type E	Green	Copper Silver Coated	-60 °C	200 °C	600 V	2.89 mm	0.114 "	12 AWG			19	25 AWG	Polytetrafluoroethylene (PTFE)	0.3 mm	0.012 in	152.4 m	500 ft
ALPHA WIRE 5859/12 WH001	Hook-Up	MIL-W-16878/4 Type E	White	Copper Silver Coated	-60 °C	200 °C	600 V	2.89 mm	0.114 "	12 AWG			19	25 AWG	Polytetrafluoroethylene (PTFE)	0.3 mm	0.012 in	304.8 m	1000 ft
ALPHA WIRE 5859/12 WH005	Hook-Up	MIL-W-16878/4 Type E	White	Copper Silver Coated	-60 °C	200 °C	600 V	2.89 mm	0.114 "	12 AWG	100 ft	30.5 m	19	25 AWG	Polytetrafluoroethylene (PTFE)	0.3 mm	0.012 in
ALPHA WIRE 5859/12 RD002	Hook-Up	MIL-W-16878/4 Type E	Red	Copper Silver Coated	-60 °C	200 °C	600 V	2.89 mm	0.114 "	12 AWG			19	25 AWG	Polytetrafluoroethylene (PTFE)	0.3 mm	0.012 in	152.4 m	500 ft
