KHEA30F Series

Catalog

AC/DC DIN RAIL SUPPLY 12V 30W

Part	Features	Applications	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Voltage - Isolation	Operating Temperature [Max]	Operating Temperature [Min]	Input Type	Current - Output (Max) [Max]	Voltage - Output 1	Efficiency	Power (Watts)	Number of Outputs	Approval Agency	Current - Output (Max)
Cosel USA, Inc. KHEA30F-12	Adjustable Output Universal Input	ITE (Commercial)	94.5 mm	75 mm	2.95 in	0.89 in	3.72 "	22.5 mm	264 VAC	85 VAC	3000 V	70 °C	-20 °C	AC	2.3 A	12 V	88.5 %	30 Watts	1	CE cULus cURus TUV
Cosel USA, Inc. KHEA30F-5	Adjustable Output Universal Input	ITE (Commercial)	94.5 mm	75 mm	2.95 in	0.89 in	3.72 "	22.5 mm	264 VAC	85 VAC	3000 V	70 °C	-20 °C	AC		5 V	85 %	30 Watts	1	CE cULus cURus TUV	5 A
Cosel USA, Inc. KHEA30F-24	Adjustable Output Universal Input	ITE (Commercial)	94.5 mm	75 mm	2.95 in	0.89 in	3.72 "	22.5 mm	264 VAC	85 VAC	3000 V	70 °C	-20 °C	AC	1.3 A	24 V	89 %	30 Watts	1	CE cULus cURus TUV
