842-050 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 50POS 0.100
| Part | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Contact Type | Color | Flange Feature | Termination Rows | Contact Material | Contact Finish | Pitch | Pitch | Material - Insulation | Gender | Number of Positions/Bay/Row | Card Type | Card Thickness [Max] | Card Thickness [Min] | Read Out | Number of Rows | Termination Rows [custom] | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 50 | 125 °C | -40 C | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Through Hole | Cantilever | Green | 4-40 Flush Mount Threaded Insert Top Opening | 1 | Copper Alloy | Gold | 0.1 " | 2.54 mm | Diallyl Phthalate (DAP) | Female | 50 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | ||||
 EDAC Inc. | 50 | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | Through Hole | Cantilever | Green | Flush Mount Side Opening Unthreaded | Copper Alloy | Gold | 0.1 " | 2.54 mm | Diallyl Phthalate (DAP) | Female | 25 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 2 | 2 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 50 | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | Through Hole | Cantilever | Green | Flush Mount Top Opening Unthreaded | 1 | Copper Alloy | Gold | 0.1 " | 2.54 mm | Diallyl Phthalate (DAP) | Female | 50 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 50 | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Right Angle Through Hole | Cantilever | Green | Flush Mount Side Opening Unthreaded | 1 | Copper Alloy | Gold | 0.1 " | 2.54 mm | Diallyl Phthalate (DAP) | Female | 50 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 50 | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Right Angle Through Hole | Cantilever | Green | Flush Mount Side Opening Unthreaded | Copper Alloy | Gold | 0.1 " | 2.54 mm | Diallyl Phthalate (DAP) | Female | 25 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 2 | 2 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 50 | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | Through Hole | Cantilever | Green | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Gold | 0.1 " | 2.54 mm | Diallyl Phthalate (DAP) | Female | 25 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 2 | 2 | ||||
 EDAC Inc. | 50 | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | Through Hole | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | Diallyl Phthalate (DAP) | Female | 25 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 2 | 2 | |||||
 EDAC Inc. | 50 | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Right Angle Through Hole | Cantilever | Green | Flush Mount M3 Threaded Insert Top Opening | 1 | Copper Alloy | Gold | 0.1 " | 2.54 mm | Diallyl Phthalate (DAP) | Female | 50 | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | ||||
 EDAC Inc. | 50 | 125 °C | -40 C | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Through Hole | Cantilever | Green | Floating Bobbin Flush Mount | Copper Alloy | Gold | 0.1 " | 2.54 mm | Diallyl Phthalate (DAP) | Female | 25 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 2 | 2 | 0.116 " | 2.95 mm | ||
 EDAC Inc. | 50 | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Through Hole | Cantilever | Green | Flush Mount Top Opening Unthreaded | Copper Alloy | Gold | 0.1 " | 2.54 mm | Diallyl Phthalate (DAP) | Female | 25 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 2 | 2 | 0.156 " | 3.96 mm |
