RAYCHEM RP-4800 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RP-4800-NO.7-4-STK
| Part | Material | Recovered Wall Thickness | Recovered Wall Thickness | Inner Diameter - Supplied [diameter] | Inner Diameter - Supplied [diameter] | Shrink Temperature | Type | Operating Temperature [Min] | Operating Temperature [Max] | Inner Diameter - Recovered [diameter] | Inner Diameter - Recovered [diameter] | Features | Color | Shrinkage Ratio | Length [x] | Length [x] | Shelf Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | 0.045 in | 1.14 mm | 76.2 mm | 3 in | 95 °C | Tubing Flexible | -55 C | 135 °C | 21.34 mm | 0.84 " | Abrasion Resistant Chemical Resistant Flame Retardant Fluid Resistant Solvent Resistant | Yellow | 4 to 1 | 4 ft | 1.22 m | |
 TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | 0.045 in | 1.14 mm | 50.8 mm | 2 in | 95 °C | Tubing Flexible | -55 C | 135 °C | 13.97 mm | 0.55 " | Abrasion Resistant Chemical Resistant Flame Retardant Fluid Resistant Solvent Resistant | Black | 4 to 1 | 4 ft | 1.22 m | 144 Months |
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | 0.045 in | 1.14 mm | 25.4 mm | 1 in | 95 °C | Tubing Flexible | -55 C | 135 °C | 6.99 mm | 0.275 in | Abrasion Resistant Chemical Resistant Flame Retardant Fluid Resistant Solvent Resistant | Black | 4 to 1 | 4 ft | 1.22 m | 144 Months |
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | 0.045 in | 1.14 mm | 50.8 mm | 2 in | 95 °C | Tubing Flexible | -55 C | 135 °C | 13.97 mm | 0.55 " | Red | 4 to 1 | 144 Months | |||
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | 0.045 in | 1.14 mm | 25.4 mm | 1 in | 95 °C | Tubing Flexible | -55 C | 135 °C | 6.99 mm | 0.275 in | Yellow | 4 to 1 | 144 Months | |||
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | 0.045 in | 1.14 mm | 76.2 mm | 3 in | 95 °C | Tubing Flexible | -55 C | 135 °C | 20.57 mm | 0.81 " | Abrasion Resistant Chemical Resistant Flame Retardant Fluid Resistant Solvent Resistant | Black | 4 to 1 | 4 ft | 1.22 m | 144 Months |
 TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | 0.045 in | 1.14 mm | 76.2 mm | 3 in | 95 °C | Tubing Flexible | -55 C | 135 °C | 20.57 mm | 0.81 " | Abrasion Resistant Chemical Resistant Flame Retardant Fluid Resistant Solvent Resistant | White | 4 to 1 | |||
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | 0.045 in | 1.14 mm | 114.3 mm | 4.5 in | 95 °C | Tubing Flexible | -55 C | 135 °C | 36.83 mm | 1.45 in | Abrasion Resistant Chemical Resistant Flame Retardant Fluid Resistant Solvent Resistant | White | 4 to 1 | |||
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | 0.045 in | 1.14 mm | 4.75 mm | 0.187 " | 95 °C | Tubing Flexible | -55 C | 135 °C | 2.36 mm | 0.093 in | Abrasion Resistant Chemical Resistant Flame Retardant Fluid Resistant Solvent Resistant | Black | 4 to 1 | |||
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | 0.045 in | 1.14 mm | 60.3 mm | 2.374 in | 95 °C | Tubing Flexible | -55 C | 135 °C | 17.3 mm | 0.681 in | Abrasion Resistant Chemical Resistant Flame Retardant Fluid Resistant Solvent Resistant | White | 4 to 1 | 4 ft | 1.22 m |
