892-032 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 32POS 0.100
...
| Part | Contact Finish | Card Type | Pitch [x] | Pitch [x] | Contact Type | Flange Feature | Termination | Number of Rows | Color | Contact Material | Material - Insulation | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Termination Rows | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Number of Positions/Bay/Row [custom] | Read Out | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Gold | Non Specified - Single Edge | 2.54 mm | 0.1 in | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Solder Eyelet(s) | 1 | Black | Copper Alloy | Polyphenylene Sulfide (PPS) | Through Hole | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | 125 °C | -40 °C | Female | 32 | Single | ||
 EDAC Inc. | Gold | Non Specified - Single Edge | 2.54 mm | 0.1 in | Cantilever | Wire Wrap | 1 | Black | Copper Alloy | Polyphenylene Sulfide (PPS) | Through Hole | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | 125 °C | -40 °C | Female | 32 | Single | |||
 EDAC Inc. | Gold | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Cantilever | Solder | 2 | Black | Copper Alloy | Polyphenylene Sulfide (PPS) | Through Hole | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 125 °C | -40 °C | Female | 16 | Dual | |||
 EDAC Inc. | Gold | Non Specified - Single Edge | 2.54 mm | 0.1 in | Cantilever | Floating Bobbin Flush Mount | Solder Eyelet(s) | 1 | Black | Copper Alloy | Polyphenylene Sulfide (PPS) | Through Hole | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | 125 °C | -40 °C | Female | 32 | Single | 0.116 in | 2.95 mm |
 EDAC Inc. | Gold | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Cantilever | Flush Mount Top Opening Unthreaded | Solder Eyelet(s) | 2 | Black | Copper Alloy | Polyphenylene Sulfide (PPS) | Through Hole | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 125 °C | -40 °C | Female | 16 | Dual | 0.156 in | 3.96 mm |
 EDAC Inc. | Gold | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Cantilever | Flush Mount M3 Threaded Insert Top Opening | Solder | 2 | Black | Copper Alloy | Polyphenylene Sulfide (PPS) | Through Hole | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 125 °C | -40 °C | Female | 16 | Dual | ||
 EDAC Inc. | Gold | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Cantilever | Solder Eyelet(s) | 2 | Black | Copper Alloy | Polyphenylene Sulfide (PPS) | Through Hole | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 125 °C | -40 °C | Female | 16 | Dual | |||
 EDAC Inc. | Gold | Non Specified - Single Edge | 2.54 mm | 0.1 in | Cantilever | Floating Bobbin Flush Mount | Wire Wrap | 1 | Black | Copper Alloy | Polyphenylene Sulfide (PPS) | Through Hole | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | 125 °C | -40 °C | Female | 32 | Single | 0.116 in | 2.95 mm |
 EDAC Inc. | Gold | Non Specified - Single Edge | 2.54 mm | 0.1 in | Cantilever | Flush Mount Top Opening Unthreaded | Wire Wrap | 1 | Black | Copper Alloy | Polyphenylene Sulfide (PPS) | Through Hole | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | 125 °C | -40 °C | Female | 32 | Single | 0.128 " | 3.25 mm |
 EDAC Inc. | Gold | Non Specified - Dual Edge | 2.54 mm | 0.1 in | Cantilever | Flush Mount Side Opening Unthreaded | Wire Wrap | 2 | Black | Copper Alloy | Polyphenylene Sulfide (PPS) | Through Hole | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | 125 °C | -40 °C | Female | 16 | Dual | 0.128 " | 3.25 mm |
