P53-1580 Series

Manufacturer: Polytron

Catalog

AC/DC CONVERTER 5V +/-15V

Part	Line Regulation	Load Regulation	Current - Output (Max)	Current - Output (Max)	Current - Output (Max)	Approval Agency	Number of Outputs	Package / Case	Mounting Type	Voltage - Output 2	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Voltage - Input [Max]	Voltage - Input [Min]	Applications	Voltage - Output 1	Voltage - Output 3	Type	Current - Output 1	Voltage - Isolation	Current - Output 2	Current - Output 3
Polytron P53-1580XA/MHIA	0.02 %	0.1 %	150 mA	1 A	150 mA	CE cURus	3	7-DIP Module	Through Hole	15 V	71 °C	-25 °C	51 mm	63.5 mm	2.5 "	3.5 "	88.9 mm	2.01 "	230 VAC	105 VAC	Medical	5 V	-15 V	Enclosed
Polytron P53-1580T/MHIA						CE cURus	3		Chassis Mount	15 V	71 °C	-25 °C	50.8 mm	63.5 mm	2.5 "	4.1 "	104.1 mm	2 in	125 VAC	105 VAC	Medical	5 V	-15 V	Enclosed	1 A	4000 V	150 mA	150 mA
Polytron P53-1580XE/MHIA	0.02 %	0.1 %	150 mA	1 A	150 mA	CE cURus	3	7-DIP Module	Through Hole	15 V	71 °C	-25 °C	51 mm	63.5 mm	2.5 "	3.5 "	88.9 mm	2.01 "	240 VAC	105 VAC	Medical	5 V	-15 V	Enclosed
