392-053 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 53POS 0.100
| Part | Termination Rows | Material - Insulation | Termination | Read Out | Contact Material | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Finish | Gender | Number of Positions/Bay/Row | Contact Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Number of Rows | Card Thickness [Max] | Card Thickness [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Wire Wrap | Single | Copper Alloy | Through Hole | 0.25 Ám | 10 Áin | 53 | Non Specified - Single Edge | -40 C | 105 ░C | Black | Gold | Female | 53 | Cantilever | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.1 " | 2.54 mm | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | Single | Copper Alloy | Through Hole | 0.25 Ám | 10 Áin | 53 | Non Specified - Single Edge | -40 C | 105 ░C | Black | Gold | Female | 53 | Cantilever | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | 0.1 " | 2.54 mm | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder Wire Wrap | Single | Copper Alloy | Right Angle Through Hole | 0.25 Ám | 10 Áin | 53 | Non Specified - Single Edge | -40 C | 105 ░C | Black | Gold | Female | 53 | Cantilever | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.1 " | 2.54 mm | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | Single | Copper Alloy | Through Hole | 0.25 Ám | 10 Áin | 53 | Non Specified - Single Edge | -40 C | 105 ░C | Black | Gold | Female | 53 | Cantilever | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.1 " | 2.54 mm | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | Single | Copper Alloy | Through Hole | 0.25 Ám | 10 Áin | 53 | Non Specified - Single Edge | -40 C | 105 ░C | Black | Gold | Female | 53 | Cantilever | 0.1 " | 2.54 mm | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Wire Wrap | Single | Copper Alloy | Through Hole | 0.25 Ám | 10 Áin | 53 | Non Specified - Single Edge | -40 C | 105 ░C | Black | Gold | Female | 53 | Cantilever | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Wire Wrap | Single | Copper Alloy | Through Hole | 0.25 Ám | 10 Áin | 53 | Non Specified - Single Edge | -40 C | 105 ░C | Black | Gold | Female | 53 | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | 0.1 " | 2.54 mm | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder Wire Wrap | Single | Copper Alloy | Right Angle Through Hole | 0.25 Ám | 10 Áin | 53 | Non Specified - Single Edge | -40 C | 105 ░C | Black | Gold | Female | 53 | Cantilever | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 0.1 " | 2.54 mm | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | Single | Copper Alloy | Through Hole | 0.25 Ám | 10 Áin | 53 | Non Specified - Single Edge | -40 C | 105 ░C | Black | Gold | Female | 53 | Cantilever | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 0.1 " | 2.54 mm | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Wire Wrap | Single | Copper Alloy | Through Hole | 0.25 Ám | 10 Áin | 53 | Non Specified - Single Edge | -40 C | 105 ░C | Black | Gold | Female | 53 | Cantilever | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 0.1 " | 2.54 mm | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
