Pch -30V -4.5A Power MOSFET
Description
AI
RW4E045AJ is a Pch -30V MOSFET for DC/DC converters, switching, battery switches.
Beta
⌘K
Pch -30V -4.5A Power MOSFET
Pch -30V -4.5A Power MOSFET
| Part | Mounting Type | Supplier Device Package | Vgs (Max) | Power Dissipation (Max) [Max] | FET Type | Rds On (Max) @ Id, Vgs | Input Capacitance (Ciss) (Max) @ Vds | Technology | Gate Charge (Qg) (Max) @ Vgs | Package / Case | Current - Continuous Drain (Id) @ 25°C | Drain to Source Voltage (Vdss) | Drive Voltage (Max Rds On, Min Rds On) | Operating Temperature | Vgs(th) (Max) @ Id | Input Capacitance (Ciss) (Max) @ Vds [Max] | Drive Voltage (Max Rds On, Min Rds On) [Max] | Drive Voltage (Max Rds On, Min Rds On) [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | Surface Mount | DFN1616-7T | 20 V | 1.5 W | P-Channel | 48 mOhm | 485 pF | MOSFET (Metal Oxide) | 11 nC | 6-PowerUFDFN | 4.5 A | 30 V | 4.5 V 10 V | 150 °C | 2.5 V | |||
Rohm Semiconductor | Surface Mount | DFN1616-7T | 12 V | 1.5 W | N-Channel | 40 mOhm | MOSFET (Metal Oxide) | 4 nC | 6-PowerUFDFN | 4.5 A | 30 V | 150 °C | 1.5 V | 450 pF | 2.5 V | 4.5 V |
