Mini50 Unsealed Header, Right-Angle, SMT, Dual Row, 16 Circuits, Gold (Au) Plating, Polarization Option A, Black, Tape and Reel
Mini50 Unsealed Header, Right-Angle, SMT, Dual Row, 16 Circuits, Gold (Au) Plating, Polarization Option A, Black, Tape and Reel
Mini50 Unsealed Header, Right-Angle, SMT, Dual Row, 16 Circuits, Gold (Au) Plating, Polarization Option A, Black, Tape and Reel
| Part | Applications | Number of Positions Loaded | Number of Rows | Features | Mounting Type | Contact Finish - Mating | Contact Finish - Post | Contact Material | Number of Positions | Contact Length - Mating | Contact Length - Mating | Style | Material Flammability Rating | Fastening Type | Insulation Height | Insulation Height | Contact Type | Contact Shape | Shrouding | Pitch - Mating [x] | Pitch - Mating [x] | Termination | Insulation Color | Connector Type | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | |||||||||||||||||||||||||
 Molex | Automotive | All | 2 | Solder Retention | Surface Mount Right Angle | Gold | Tin | Brass | 20 | 5.55 mm | 0.218 in | Board to Cable/Wire | UL94 V-0 | Latch Holder | 0.46 in | 11.68 mm | Male Blade | Rectangular | Shrouded - 4 Wall | 0.079 in | 2 mm | Solder | Gray | Header | |
 Molex | Automotive | All | 2 | Solder Retention | Surface Mount Right Angle | Tin | Brass | 5.55 mm | 0.218 in | Board to Cable/Wire | UL94 V-0 | Latch Holder | 0.46 in | 11.68 mm | Male Blade | Rectangular | Shrouded - 4 Wall | 0.079 in | 2 mm | Solder | Black | Header | 16 | ||
Molex | Automotive | All | 2 | Solder Retention | Surface Mount Right Angle | Gold | Tin | Brass | 12 | 5.55 mm | 0.218 in | Board to Cable/Wire | UL94 V-0 | Latch Holder | 0.46 in | 11.68 mm | Male Blade | Rectangular | Shrouded - 4 Wall | 0.079 in | 2 mm | Solder | Gray | Header | |
 Molex | Automotive | All | 2 | Solder Retention | Surface Mount Right Angle | Tin | Brass | 24 | 5.55 mm | 0.218 in | Board to Cable/Wire | UL94 V-0 | Latch Holder | 0.46 in | 11.68 mm | Male Blade | Rectangular | Shrouded - 4 Wall | 0.079 in | 2 mm | Solder | Gray | Header | ||
 Molex | Automotive | All | 2 | Solder Retention | Surface Mount Right Angle | Gold | Tin | Brass | 24 | 5.55 mm | 0.218 in | Board to Cable/Wire | UL94 V-0 | Latch Holder | 0.46 in | 11.68 mm | Male Blade | Rectangular | Shrouded - 4 Wall | 0.079 in | 2 mm | Solder | Gray | Header | |
Molex | |||||||||||||||||||||||||
 Molex | Automotive | All | 2 | Solder Retention | Surface Mount Right Angle | Tin | Brass | 24 | 5.55 mm | 0.218 in | Board to Cable/Wire | UL94 V-0 | Latch Holder | 0.46 in | 11.68 mm | Male Blade | Rectangular | Shrouded - 4 Wall | 0.079 in | 2 mm | Solder | Gray | Header | ||
Molex | |||||||||||||||||||||||||
 Molex | Automotive | All | 2 | Solder Retention | Surface Mount Right Angle | Gold | Brass | 12 | 5.55 mm | 0.218 in | Board to Cable/Wire | UL94 V-0 | Latch Holder | 0.46 in | 11.68 mm | Male Blade | Rectangular | Shrouded - 4 Wall | 0.079 in | 2 mm | Solder | Black | Header |
