83321E Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2CON 18AWG WHT SHLD
| Part | Shield Material | Shield Coverage | Conductor Strand [custom] | Conductor Strand [custom] | Conductor Material | Length [x] | Length [x] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Conductors | Jacket Color | Wire Gauge | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Cable Type | Conductor Insulation | Jacket (Insulation) Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Shield Type | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Copper Silver Coated | 85 % | 30 AWG | 19 | Copper Silver Coated | 100 ft | 30.5 m | -65 ░C | 200 °C | 2 | White | 18 AWG | 0.279 mm | 0.011 " | Multi-Conductor | Tetrafluoroethylene (TFE) | Tetrafluoroethylene (TFE) | 4.55 mm | 0.179 " | Braid | ||
 Belden Inc. | Copper Silver Coated | 85 % | 30 AWG | 19 | Copper Silver Coated | -65 ░C | 200 °C | 2 | White | 18 AWG | 0.279 mm | 0.011 " | Multi-Conductor | Tetrafluoroethylene (TFE) | Tetrafluoroethylene (TFE) | 4.55 mm | 0.179 " | Braid | 304.8 m | 1000 ft | ||
Belden Inc. | Copper Silver Coated | 85 % | 30 AWG | 19 | Copper Silver Coated | -65 ░C | 200 °C | 2 | White | 18 AWG | 0.279 mm | 0.011 " | Multi-Conductor | Tetrafluoroethylene (TFE) | Tetrafluoroethylene (TFE) | 4.55 mm | 0.179 " | Braid | 152.4 m | 500 ft |
