661-015 Series
Manufacturer: EDAC Inc.
Beta
⌘K
661 SERIES RIGHT ANGLE DUAL D-SU
| Part | Dielectric Material | Contact Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Contact Finish | Shell Material, Finish | Backset Spacing | Backset Spacing | Current Rating (Amps) | Connector Style | Connector Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Material Flammability Rating | Termination | Flange Feature | Contact Finish Thickness | Number of Positions | Number of Positions | Features | Number of Rows [custom] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | Brass | Black | -55 C | 85 °C | Signal | Gold | Nickel Plated Steel | 8.08 mm | 0.318 " | 3 A | D-Sub - Stacked | Plug Male Pins | 2 | 2 | UL94 V-0 | Solder | Housing/Shell (Unthreaded) | Flash | 15 | 15 | Board Lock Grounding Indents Mounting Brackets Shielded | 2 | Panel Mount Right Angle Through Hole | |||
 EDAC Inc. | Polyester Thermoplastic | Brass | Black | -55 C | 85 °C | Signal | Gold | Nickel Plated Steel | 8.08 mm | 0.318 " | 3 A | D-Sub - Stacked | Plug Male Pins | 2 | 2 | UL94 V-0 | Solder | Housing/Shell (M3) | 15 | 15 | Board Lock Grounding Indents Mounting Brackets Shielded | 2 | Panel Mount Right Angle Through Hole | 0.38 µm | 15 µin | ||
 EDAC Inc. | Polyester Thermoplastic | Brass | Black | -55 C | 85 °C | Signal | Gold | Nickel Plated Steel | 8.08 mm | 0.318 " | 3 A | D-Sub - Stacked | Plug Male Pins | 2 | 2 | UL94 V-0 | Solder | 4-40 Mating Side Female Screwlock | 15 | 15 | Grounding Indents Mounting Brackets Shielded | 2 | Panel Mount Right Angle Through Hole | 0.76 Ám | 30 Áin | ||
 EDAC Inc. | Polyester Thermoplastic | Brass | Black | -55 C | 85 °C | Signal | Gold | Nickel Plated Steel | 8.08 mm | 0.318 " | 3 A | D-Sub - Stacked | Plug Male Pins | 2 | 2 | UL94 V-0 | Solder | Housing/Shell (Unthreaded) | 15 | 15 | Grounding Indents Mounting Brackets Shielded | 2 | Panel Mount Right Angle Through Hole | 0.38 µm | 15 µin | ||
 EDAC Inc. | Polyester Thermoplastic | Brass | Black | -55 C | 85 °C | Signal | Gold | Nickel Plated Steel | 8.08 mm | 0.318 " | 3 A | D-Sub - Stacked | Plug Male Pins | 2 | 2 | UL94 V-0 | Solder | Housing/Shell (M3) | Flash | 15 | 15 | Board Lock Grounding Indents Mounting Brackets Shielded | 2 | Panel Mount Right Angle Through Hole | |||
 EDAC Inc. | Polyester Thermoplastic | Brass | Black | -55 C | 85 °C | Signal | Gold | Nickel Plated Steel | 8.08 mm | 0.318 " | 3 A | D-Sub - Stacked | Plug Male Pins | 2 | 2 | UL94 V-0 | Solder | 4-40 Mating Side Female Screwlock | 15 | 15 | Board Lock Grounding Indents Mounting Brackets Shielded | 2 | Panel Mount Right Angle Through Hole | 0.38 µm | 15 µin | ||
 EDAC Inc. | Polyester Thermoplastic | Brass | Black | -55 C | 85 °C | Signal | Gold | Nickel Plated Steel | 8.08 mm | 0.318 " | 3 A | D-Sub - Stacked | Plug Male Pins | 2 | 2 | UL94 V-0 | Solder | Housing/Shell | 15 | 15 | Board Lock Grounding Indents Mounting Brackets Shielded | 2 | Panel Mount Right Angle Through Hole | 0.38 µm | 15 µin | 4-40 | |
 EDAC Inc. | Polyester Thermoplastic | Brass | Black | -55 C | 85 °C | Signal | Gold | Nickel Plated Steel | 8.08 mm | 0.318 " | 3 A | D-Sub - Stacked | Plug Male Pins | 2 | 2 | UL94 V-0 | Solder | Housing/Shell (M3) | 15 | 15 | Board Lock Grounding Indents Mounting Brackets Shielded | 2 | Panel Mount Right Angle Through Hole | 0.76 Ám | 30 Áin | ||
 EDAC Inc. | Polyester Thermoplastic | Brass | Black | -55 C | 85 °C | Signal | Gold | Nickel Plated Steel | 8.08 mm | 0.318 " | 3 A | D-Sub - Stacked | Plug Male Pins | 2 | 2 | UL94 V-0 | Solder | Housing/Shell | 15 | 15 | Board Lock Grounding Indents Mounting Brackets Shielded | 2 | Panel Mount Right Angle Through Hole | 0.76 Ám | 30 Áin | 4-40 | |
 EDAC Inc. | Polyester Thermoplastic | Brass | Black | -55 C | 85 °C | Signal | Gold | Nickel Plated Steel | 8.08 mm | 0.318 " | 3 A | D-Sub - Stacked | Plug Male Pins | 2 | 2 | UL94 V-0 | Solder | Housing/Shell (Unthreaded) | 15 | 15 | Board Lock Grounding Indents Mounting Brackets Shielded | 2 | Panel Mount Right Angle Through Hole | 0.76 Ám | 30 Áin |
