PHE840 Series

Manufacturer: KEMET

Catalog

CAP FILM 6.8UF 20% 760VDC RADIAL

Part	Lead Spacing	Lead Spacing	Mounting Type	Package / Case	Height - Seated (Max) [Max]	Height - Seated (Max)	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Ratings	Voltage Rating - AC	Applications	Voltage Rating - DC	Tolerance	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Capacitance	Dielectric Material	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Size / Dimension [y]
KEMET PHE840MR7680MR06R06L2	37.5 mm	1.476 in	Through Hole	Radial	1.496 in	38 mm	1.614 in	0.827 in	21 mm	41 mm	X2	275 V	EMI RFI Suppression	760 V	20 %	-55 C	105 ░C	PC Pins	6.8 µF	Polypropylene (PP) Metallized
KEMET PHE840EA5220MA01R17	10 mm	0.394 in	Through Hole	Radial	0.354 in		0.512 "	0.157 "	4 mm	13 mm	X2	300 V	EMI RFI Suppression	760 V	20 %	-55 C	105 ░C	PC Pins	0.022 µF	Polypropylene (PP) Metallized	9 mm
KEMET PHE840EZ7220MF14R25L2	27.5 mm	1.083 in	Through Hole	Radial			1.24 in	0.689 in	17.5 mm	31.5 mm	X2	300 V	EMI RFI Suppression	760 V	20 %	-55 C	105 ░C	PC Pins	2.2 µF	Polypropylene (PP) Metallized		1.102 in	28 mm
KEMET PHE840ED7100MD20R06L2	22.5 mm	0.886 in	Through Hole	Radial			1.024 in	0.531 in	13.5 mm	26 mm	X2	300 V	EMI RFI Suppression	760 V	20 %	-55 C	105 ░C	PC Pins	1 µF	Polyester Metallized		0.906 in	23 mm
KEMET PHE840MK5470MK04R17	7.5 mm	0.295 in	Through Hole	Radial	0.472 in	12 mm					X2	275 V	EMI RFI Suppression	760 V	20 %	-55 C	105 ░C	PC Pins		Polypropylene (PP) Metallized
KEMET PHE840MD6220MD13R30L1	22.5 mm	0.886 in	Through Hole	Radial	0.571 "		1.024 in	0.256 "	6.5 mm	26 mm	X2	275 V	EMI RFI Suppression	760 V	20 %	-55 C	105 ░C	PC Pins	0.22 µF	Polypropylene (PP) Metallized	14.5 mm
KEMET PHE840MB6100MB05R05	15 mm	0.591 in	Through Hole	Radial			0.709 in	0.217 in	5.5 mm	18 mm	X2	275 V	EMI RFI Suppression	760 V	20 %	-55 C	105 ░C	PC Pins	100000 pF	Polypropylene (PP) Metallized	0.492 in			12.5 mm
KEMET PHE840EF7100KF12R06L2	27.5 mm	1.083 in	Through Hole	Radial	0.886 in		1.24 in	0.453 in		31.5 mm	X2	300 V	EMI RFI Suppression	760 V	10 %	-55 C	105 ░C	PC Pins	1 µF	Polypropylene (PP) Metallized	22.5 mm				11.5 mm
KEMET PHE840MB6470MB16R17	15 mm	0.591 in	Through Hole	Radial			0.709 in	0.433 in	11 mm	18 mm	X2	275 V	EMI RFI Suppression	760 V	20 %	-55 C	105 ░C	PC Pins	0.47 µF	Polypropylene (PP) Metallized		0.748 in	19 mm
KEMET PHE840MR7220MR05R06L2	37.5 mm	1.476 in	Through Hole	Radial	0.945 "		1.614 in 41 mm	0.512 " 13 mm			X2	275 V	EMI RFI Suppression	760 V	20 %	-55 C	105 ░C	PC Pins	2.2 µF	Polypropylene (PP) Metallized	24 mm
