MMT371A Series
Manufacturer: METZ CONNECT USA Inc.
Beta
⌘K
CONN JACK FMALE 8POS GOLD SOLDER
| Part | Number of Positions | Applications | Voltage Rating | Shell Material | Color | Mounting Type | Termination | Shielding | Primary Material | Ingress Protection | Orientation [x] | Features | Connector Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shell Size - Insert | Contact Finish - Mating | Fastening Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Current Rating (Amps) | Mounting Feature | Insert Material [custom] | Insert Material [custom] | Orientation | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 METZ CONNECT USA Inc. | 8 | Railway | 50 VAC 60 VDC | Copper Zinc | Silver | Panel Mount Through Hole | Solder | Shielded | Metal | IP67 - Dust Tight Waterproof | X | Potted | Jack Female Sockets | 8 µin | 0.203 µm | M12-8 | Gold | Threaded | 85 °C | -40 C | Copper Zinc | 0.5 A | Bulkhead - Front Side Nut | ||||
 METZ CONNECT USA Inc. | 4 | Industrial | 250 V | Copper Zinc | Silver | Panel Mount Through Hole | Solder | Shielded | Metal | IP67 - Dust Tight Waterproof | Board Guide Potted | Jack Female Sockets | 7.87 Áin | 0.2 Ám | M12-4 | Gold | Threaded | 85 °C | -40 C | Copper Zinc | 4 A | Bulkhead - Front Side Nut | Nylon | Polyamide (PA) | D | UL94 V-0 | |
 METZ CONNECT USA Inc. | 8 | Railway | 50 VAC 60 VDC | Copper Zinc | Silver | Panel Mount Through Hole | Solder | Shielded | Metal | IP67 - Dust Tight Waterproof | X | Jack Female Sockets | M12-8 | Gold | Threaded | 85 °C | -40 C | Copper Zinc | 0.5 A | Bulkhead - Front Side Nut | |||||||
 METZ CONNECT USA Inc. | 4 | Industrial | 250 V | Copper Zinc | Silver | Panel Mount Through Hole | Solder | Shielded | Metal | IP67 - Dust Tight Waterproof | Board Guide | Jack Female Sockets | 7.87 Áin | 0.2 Ám | M12-4 | Gold | Threaded | 85 °C | -40 C | Copper Zinc | 4 A | Bulkhead - Front Side Nut | Nylon | Polyamide (PA) | D | UL94 V-0 | |
 METZ CONNECT USA Inc. | 4 | Industrial | 250 V | Copper Zinc | Silver | Panel Mount Through Hole | Solder | Shielded | Metal | IP67 - Dust Tight Waterproof | Board Guide | Jack Female Sockets | 7.87 Áin | 0.2 Ám | M12-4 | Gold | Threaded | 85 °C | -40 C | Copper Zinc | 4 A | Bulkhead - Front Side Nut | Nylon | Polyamide (PA) | D | UL94 V-0 | |
 METZ CONNECT USA Inc. | 8 | Railway | 50 VAC 60 VDC | Copper Zinc | Silver | Panel Mount Through Hole | Solder | Shielded | Metal | IP67 - Dust Tight Waterproof | X | Board Guide | Jack Female Sockets | 8 µin | 0.203 µm | M12-8 | Gold | Threaded | 85 °C | -40 C | Copper Zinc | Bulkhead - Front Side Nut |
