5535 Series

Catalog

CABLE 5COND 16AWG TAN SHLD 1000'

Part	Shield Material	Shield Coverage	Ratings	Conductor Insulation	Jacket (Insulation) Material	Features	Number of Conductors	Cable Type	Jacket Color	Conductor Material	Wire Gauge	Operating Temperature [Min]	Operating Temperature [Max]	Length	Length	Shield Type	Voltage	Conductor Strand [custom]	Conductor Strand [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length [x]	Length [x]
ALPHA WIRE 5535 TN199	Aluminum Copper Tinned	70 % 100 %	UL Style 2501	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	Drain Wire Rip Cord	5	Multi-Conductor	Tan	Copper Tinned	16 AWG	-30 ░C	105 ░C	304.8 m	1000 ft	Braid Foil	600 V	19	0.0117 in	0.492 in	12.5 mm	1.6 mm	0.063 in
ALPHA WIRE 5535 SL005	Aluminum Copper Tinned	70 % 100 %	UL Style 2501	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	Drain Wire Rip Cord	5	Multi-Conductor	Slate	Copper Tinned	16 AWG	-30 ░C	105 ░C			Braid Foil	600 V	19	0.0117 in	0.492 in	12.5 mm	1.6 mm	0.063 in	100 ft	30.5 m
ALPHA WIRE 5535 SL001	Aluminum Copper Tinned	70 % 100 %	UL Style 2501	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	Drain Wire Rip Cord	5	Multi-Conductor	Slate	Copper Tinned	16 AWG	-30 ░C	105 ░C	304.8 m	1000 ft	Braid Foil	600 V	19	0.0117 in	0.492 in	12.5 mm	1.6 mm	0.063 in
ALPHA WIRE 5535 SL002	Aluminum Copper Tinned	70 % 100 %	UL Style 2501	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	Drain Wire Rip Cord	5	Multi-Conductor	Slate	Copper Tinned	16 AWG	-30 ░C	105 ░C	152.4 m	500 ft	Braid Foil	600 V	19	0.0117 in	0.492 in	12.5 mm	1.6 mm	0.063 in
ALPHA WIRE 5535 SL199	Aluminum Copper Tinned	70 % 100 %	UL Style 2501	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	Drain Wire Rip Cord	5	Multi-Conductor	Slate	Copper Tinned	16 AWG	-30 ░C	105 ░C			Braid Foil	600 V	19	0.0117 in	0.492 in	12.5 mm	1.6 mm	0.063 in
