MPX21 Series
Manufacturer: NXP USA Inc.
Beta
⌘K
SENSOR 14.5PSIG 0.19" .04V
| Part | Port Style | Mounting Type | Port Diameter | Port Gender | Port Feature | Termination Style | Accuracy Range Maximum | Accuracy Range Minimum | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Features | Output Voltage (Min) | Output Voltage (Max) | Pressure Type | Output Type | Maximum Pressure | Operating Temperature (Max) | Operating Temperature (Min) | Applications | Operating Pressure | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NXP USA Inc. | Barbed | Through Hole | 0.19 " | Male | Tube | PC Pin | 0.4 % | -0.6 % | 16 V | 10 VDC | Temperature Compensated | 0 mV | 40 mV | Vented Gauge | Wheatstone Bridge | 58.02 PSI | 125 °C | -40 °C | Board Mount | 14.5 PSI | 4-SIP Module |
 NXP USA Inc. | Barbed | Through Hole | 0.19 " | Male | Tube | PC Pin | 16 V | 10 VDC | Temperature Compensated | 0 mV | 40 mV | Vented Gauge | Wheatstone Bridge | 58.02 PSI | 125 °C | -40 °C | Board Mount | 14.5 PSI | 4-SIP Module | ||
 NXP USA Inc. | Barbed | Through Hole | 0.19 " | Male | Tube | PC Pin | 16 V | 10 VDC | Temperature Compensated | 0 mV | 40 mV | Absolute | Wheatstone Bridge | 58.02 PSI | 125 °C | -40 °C | Board Mount | 14.5 PSI | 4-SIP Module | ||
 NXP USA Inc. | No Port | Through Hole | PC Pin | 16 V | 10 VDC | Temperature Compensated | 0 mV | 40 mV | Absolute | Wheatstone Bridge | 58.02 PSI | 125 °C | -40 °C | Board Mount | 14.5 PSI | 4-SIP Module |
