MLH500 Series

Manufacturer: Honeywell Sensing and Productivity Solutions

Catalog

SENSOR AMP 500PSI 4-20MA OUT

Part	Operating Pressure	Operating Pressure	Voltage - Supply [Max]	Voltage - Supply [Min]	Features	Output Type	Port Style	Pressure Type	Output [Max]	Output [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Accuracy	Maximum Pressure	Maximum Pressure	Applications	Package / Case	Port Size	Port Size	Port Size	Termination Style	Port Size [x]	Port Size [x]	Operating Pressure [x]	Operating Pressure [x]	Maximum Pressure [Max]	Maximum Pressure [Max]	Port Size [custom]	Port Size [custom]
Honeywell Sensing and Productivity Solutions MLH500PSB06B	3447.38 kPa	500 PSI	30 VDC	9.5 V	Amplified Output Temperature Compensated	Analog Current	Threaded	Sealed Gauge	20 mA	4 mA	125 °C	-40 °C	0.25 %	1500 PSI	10342.14 kPa	Industrial Automation	Cylinder Metal	0.125 "	3.18 mm	Male	Packard Metripak 150
Honeywell Sensing and Productivity Solutions MLH500PSL06A	3447.38 kPa	500 PSI	6 V	5 V	Amplified Output Temperature Compensated	Analog Voltage	Threaded	Sealed Gauge	4.5 V	0.5 V	125 °C	-40 °C	0.25 %	1500 PSI	10342.14 kPa	Industrial Automation	Cylinder Metal	0.125 "	3.18 mm	Male	Cable 1m
Honeywell Sensing and Productivity Solutions MLH500PSB09C	3447.38 kPa	500 PSI	30 VDC	8 V	Amplified Output Temperature Compensated	Analog Voltage	Threaded	Sealed Gauge	6 V	1 V	125 °C	-40 °C	0.25 %	1500 PSI	10342.14 kPa	Industrial Automation	Cylinder Metal			Female	Packard Metripak 150	11.11 mm	0.4375 "
Honeywell Sensing and Productivity Solutions MLH500BSD08E			30 VDC	7 V	Amplified Output Temperature Compensated	Analog Voltage	Threaded	Sealed Gauge	4.5 V	0.5 V	125 °C	-40 °C	0.25 %			Industrial Automation	Cylinder Metal			M10 x 1 Male	M12			7251.89 PSI	50000 kPa	10877.83 PSI	75000 kPa
Honeywell Sensing and Productivity Solutions MLH500PGL01G	3447.38 kPa	500 PSI	30 VDC	8 V	Amplified Output Temperature Compensated	Analog Voltage	Threaded	Vented Gauge	5 V	1 V	125 °C	-40 °C	0.25 %	1500 PSI	10342.14 kPa	Industrial Automation	Cylinder Metal				Cable 1m	6.35 mm	0.25 "					NPT	Male
Honeywell Sensing and Productivity Solutions MLH500BSD54E
Honeywell Sensing and Productivity Solutions MLH500PSD01B	3447.38 kPa	500 PSI	30 VDC	9.5 V	Amplified Output Temperature Compensated	Analog Current	Threaded	Sealed Gauge	20 mA	4 mA	125 °C	-40 °C	0.25 %	1500 PSI	10342.14 kPa	Industrial Automation	Cylinder Metal					6.35 mm	0.25 "					NPT	Male
Honeywell Sensing and Productivity Solutions MLH500PGL06A	3447.38 kPa	500 PSI	6 V	5 V	Amplified Output Temperature Compensated	Analog Voltage	Threaded	Vented Gauge	4.5 V	0.5 V	125 °C	-40 °C	0.25 %	1500 PSI	10342.14 kPa	Industrial Automation	Cylinder Metal	0.125 "	3.18 mm	Male
Honeywell Sensing and Productivity Solutions MLH500PST06A	3447.38 kPa	500 PSI	6 V	5 V	Amplified Output Temperature Compensated	Analog Voltage	Threaded	Sealed Gauge	4.5 V	0.5 V	125 °C	-40 °C	0.25 %	1500 PSI	10342.14 kPa	Industrial Automation	Cylinder Metal	0.125 "	3.18 mm	Male
Honeywell Sensing and Productivity Solutions MLH500BGT02A
