1825010 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

SWITCH SLIDE DPDT 300MA 115V

Part	Voltage Rating - AC	Mechanical Life	Contact Material	Termination Style	Contact Finish	Switch Function	Mounting Type	Switch Travel	Actuator Length [x]	Electrical Life	Current Rating (Amps)	Actuator Type	Operating Temperature [Min]	Operating Temperature [Max]	Operating Force	Actuator Material	Circuit	Contact Timing	Voltage Rating - DC
TE Connectivity Raychem Cable Protection 1825010-8	115 V	15000 Cycles	Copper Alloy	J Lead	Silver	On-On	Surface Mount	2.79 mm	2.79 mm	15000 Cycles	300 mA	Standard	-40 °C	80 C	950 gf	Nylon 4/6 Polyamide (PA46)	DPDT	Shorting
TE Connectivity Raychem Cable Protection 1-1825010-3	115 V	15000 Cycles	Copper Alloy	PC Pin	Silver	On-On	Through Hole	2.79 mm	2.79 mm	15000 Cycles	300 mA	Standard	-40 °C	80 C	950 gf	Nylon 4/6 Polyamide (PA46)	4PDT	Shorting
TE Connectivity Raychem Cable Protection 4-1825010-2	115 V	15000 Cycles	Copper Alloy	Gull Wing	Silver	On-On	Surface Mount	2.79 mm	2.79 mm	15000 Cycles	300 mA	Standard	-40 °C	80 C	950 gf	Nylon 4/6 Polyamide (PA46)	6PDT	Shorting
TE Connectivity Raychem Cable Protection 1-1825010-2	115 V	15000 Cycles	Copper Alloy	J Lead	Silver	On-On	Surface Mount Right Angle	2.79 mm	2.67 mm	15000 Cycles	300 mA	Standard	-40 °C	80 C	950 gf	Nylon 4/6 Polyamide (PA46)	DPDT	Shorting
TE Connectivity Raychem Cable Protection 4-1825010-6	115 V	15000 Cycles	Copper Alloy	Gull Wing	Silver	On-On	Surface Mount Right Angle	2.79 mm	5.82 mm	15000 Cycles	300 mA	Standard	-40 °C	80 C	950 gf	Nylon 4/6 Polyamide (PA46)	6PDT	Shorting
TE Connectivity Raychem Cable Protection 1-1825010-4	20 V	15000 Cycles	Copper Alloy	PC Pin	Gold	On-On	Through Hole	2.79 mm	2.79 mm	15000 Cycles	0.4 VA	Standard	-40 °C	80 C	950 gf	Nylon 4/6 Polyamide (PA46)	4PDT	Shorting	20 V
