SML-LX0603 Series

Manufacturer: Lumex Opto/Components Inc.

Catalog

LED ORANGE DIFFUSED SMD

Part	Package / Case	Package / Case	Wavelength - Peak	Lens Color	Viewing Angle	Voltage - Forward (Vf) (Typ)	Millicandela Rating	Lens Style	Size / Dimension [x]	Size / Dimension [y]	Lens Transparency	Current - Test	Height (Max) [z]	Configuration	Mounting Type	Lens Size [x]	Lens Size [y]	Color	Height (Max) [Max] [z]	Height (Max) [z]
Lumex Opto/Components Inc. SML-LX0603SOW-TR	1608 Metric	0603	610 nm	White	140 °	2 V	60 mcd	Rectangle with Flat Top	1.6 mm	0.8 mm	Diffused	20 mA	0.6 mm	Standard	Surface Mount	1 mm	0.8 mm
Lumex Opto/Components Inc. SML-LX0603YW-TR	1608 Metric	0603	585 nm	White	160 °	2.1 V	14 mcd	Rectangle with Flat Top	1.6 mm	0.8 mm	Diffused	20 mA	0.6 mm	Standard	Surface Mount	1 mm	0.8 mm	Yellow
Lumex Opto/Components Inc. SML-LX0603GW-TR	1608 Metric	0603	565 nm	White	160 °	2.2 V	18 mcd	Rectangle with Flat Top	1.6 mm	0.8 mm	Diffused	20 mA	0.6 mm	Standard	Surface Mount	1 mm	0.8 mm	Green
Lumex Opto/Components Inc. SML-LX0603SUGW-TR	1608 Metric	0603		White	140 °	2 V	71.5 mcd	Rectangle with Flat Top	1.6 mm	0.8 mm	Diffused	20 mA	0.6 mm	Standard	Surface Mount	1 mm	0.8 mm	Green
Lumex Opto/Components Inc. SML-LX0603SYW-TR	1608 Metric	0603	590 nm	White	140 °	2 V	60 mcd	Rectangle with Flat Top	1.6 mm	0.8 mm	Diffused	20 mA	0.6 mm	Standard	Surface Mount	1 mm	0.8 mm	Yellow
Lumex Opto/Components Inc. SML-LX0603SRW-TR	1608 Metric	0603	660 nm	White	120 °	1.7 V	15 mcd	Rectangle with Flat Top	1.6 mm	0.8 mm	Diffused	20 mA	0.6 mm	Standard	Surface Mount	1 mm	0.8 mm	Red
Lumex Opto/Components Inc. SML-LX0603UWD-TR	1608 Metric	0603		Yellow	140 °	3.5 V	160 mcd	Rectangle with Flat Top	1.6 mm	0.8 mm	Diffused	20 mA		Standard	Surface Mount	1 mm	0.8 mm	White	0.8 mm
Lumex Opto/Components Inc. SML-LX0603IW-TR	1608 Metric	0603	635 nm	White	160 °	2 V	14 mcd	Rectangle with Flat Top	1.6 mm	0.8 mm	Diffused	20 mA	0.6 mm	Standard	Surface Mount	1 mm	0.8 mm	Red
Lumex Opto/Components Inc. SML-LX0603SIW-TR	1608 Metric	0603	632 nm	White	128 °	2 V	71.5 mcd	Rectangle with Flat Top	1.6 mm	0.8 mm	Diffused	20 mA	0.6 mm	Standard	Surface Mount	1 mm	0.8 mm	Red
Lumex Opto/Components Inc. SML-LX0603SGW-TR	1608 Metric	0603	565 nm	White	160 °	2.2 V	20 mcd	Rectangle with Flat Top	1.6 mm	0.8 mm	Diffused	20 mA			Surface Mount	1 mm	0.8 mm	Green		0.73 mm
