B72241L Series

Catalog

VARISTOR DISC 40MM

Part	Package / Case [diameter]	Package / Case	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Maximum DC Volts [Max]	Number of Circuits	Energy	Capacitance @ Frequency	Varistor Voltage (Typ)	Varistor Voltage (Max) [Max]	Maximum AC Volts [Max]	Current - Surge	Varistor Voltage (Min) [Min]
EPCOS - TDK Electronics B72241L0171K100	40 mm	Disc	Chassis Mount	85 °C	-25 °C
EPCOS - TDK Electronics B72241L0441K100	40 mm	Disc	Chassis Mount	85 °C	-25 °C	585 V	1	950 J	1700 pF	715 V	786.5 V	440 V	50 kA	643.5 V
EPCOS - TDK Electronics B72241L0421K100		Encased Disc	Chassis Mount	85 °C	-25 °C	560 V	1	910 J	1 kHz 1800 pF	680 V	748 V	420 V	50 kA	612 V
