846-060 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 60POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Mounting Type | Number of Positions | Contact Type | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Gender | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Read Out | Color | Number of Positions/Bay/Row | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 60 | Cantilever | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 125 °C | -40 C | Solder Eyelet(s) | Dual | Green | 30 | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 60 | Cantilever | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | Solder | Dual | Green | 30 | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Right Angle Through Hole | 60 | Cantilever | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 2.95 mm | 0.116 " | Non Specified - Dual Edge | 125 °C | -40 C | Solder | Dual | Green | 30 | Floating Bobbin Flush Mount | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 60 | Cantilever | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | Solder | Dual | Green | 30 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 60 | Cantilever | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 125 °C | -40 C | Wire Wrap | Dual | Green | 30 | Side Mount Opening Unthreaded | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Board Edge Straddle Mount | 60 | Cantilever | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 3.96 mm | 0.156 " | Non Specified - Dual Edge | 125 °C | -40 C | Solder | Dual | Green | 30 | Card Extender | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 60 | Cantilever | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 125 °C | -40 C | Wire Wrap | Dual | Green | 30 | Side Mount Opening Unthreaded | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 60 | Cantilever | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 125 °C | -40 C | Solder | Dual | Green | 30 | Side Mount Opening Unthreaded | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Right Angle Through Hole | 60 | Cantilever | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 125 °C | -40 C | Solder | Dual | Green | 30 | Side Mount Opening Unthreaded | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Board Edge Straddle Mount | 60 | Cantilever | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | Solder Eyelet(s) | Dual | Green | 30 | Card Extender |
