R12555 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMA / THREAD-IN RECEPTACLE FOR P
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Mating Cycles | Center Contact Plating | Dielectric Material | Body Material | Mounting Type | Frequency - Max [Max] | Number of Ports | Connector Type | Fastening Type | Shield Termination | Center Contact Material | Contact Termination | Housing Color | Impedance | Connector Style | Voltage Rating | Features | Mounting Feature | Body Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | -65 ░C | 165 °C | 500 | Gold | Polytetrafluoroethylene (PTFE) | Stainless Steel | Panel Mount Threaded | 18 GHz | 1 | Receptacle Female Socket | Threaded | Solder | Beryllium Copper | Solder | Silver | 50 Ohms | SMA | ||||
 Radiall USA, Inc. | -65 ░C | 165 °C | 500 | Gold | Polytetrafluoroethylene (PTFE) | Stainless Steel | Panel Mount | 18 GHz | 1 | Female Socket Jack | Threaded | Solder | Beryllium Copper | Solder Cup | Silver | 50 Ohms | SMA | 335 V | Extended Insulation | Bulkhead - Front Side Nut | |
Radiall USA, Inc. | -65 ░C | 165 °C | 500 | Gold | Polytetrafluoroethylene (PTFE) | Stainless Steel | Panel Mount Threaded | 18 GHz | 1 | Receptacle Female Socket | Threaded | Solder | Beryllium Copper | Solder | Silver | 50 Ohms | SMA | ||||
Radiall USA, Inc. | -65 ░C | 165 °C | 500 | Gold | Polytetrafluoroethylene (PTFE) | Stainless Steel | Panel Mount | 18 GHz | 1 | Female Socket Jack | Threaded | Solder | Beryllium Copper | Solder Cup | Gold | 50 Ohms | SMA | 500 V | Extended Insulation | Bulkhead - Front Side Nut | Gold |
 Radiall USA, Inc. | -65 ░C | 165 °C | 500 | Gold | Polytetrafluoroethylene (PTFE) | Stainless Steel | Panel Mount | 18 GHz | 1 | Female Socket Jack | Threaded | Solder | Beryllium Copper | Solder Cup | Silver | 50 Ohms | SMA | 335 V | Extended Insulation | Bulkhead - Front Side Nut | |
 Radiall USA, Inc. | -65 ░C | 165 °C | 500 | Gold | Polytetrafluoroethylene (PTFE) | Stainless Steel | Panel Mount | 18 GHz | 1 | Female Socket Jack | Threaded | Solder | Beryllium Copper | Solder Cup | Gold | 50 Ohms | SMA | 500 V | Extended Insulation | Bulkhead - Front Side Nut | Gold |
Radiall USA, Inc. | -65 ░C | 165 °C | 500 | Gold | Polytetrafluoroethylene (PTFE) | Brass | Panel Mount Through Hole | 18 GHz | 1 | Female Socket Jack | Threaded | Solder | Bronze | Solder | Gold | 50 Ohms | SMA | Extended Insulation | Bulkhead - Rear Side Nut | Gold | |
 Radiall USA, Inc. | -65 ░C | 165 °C | 500 | Gold | Polytetrafluoroethylene (PTFE) | Brass | Panel Mount Through Hole | 18 GHz | 1 | Female Socket Jack | Threaded | Solder | Bronze | Solder | Gold | 50 Ohms | SMA | Extended Insulation | Bulkhead - Rear Side Nut | Gold |
