50ST45 Series
Manufacturer: Grayhill Inc.
Beta
⌘K
ELECTRICALSWITCH ROTARY NOTOVER5AMP
| Part | Panel Cutout Dimensions [diameter] | Index Stops | Actuator Type | Actuator Length [x] | Mounting Type | Current Rating (Amps) | Angle of Throw | Contact Timing | Voltage Rating - AC | Depth Behind Panel [custom] | Termination Style | Circuit per Deck | Number of Poles per Deck | Voltage Rating - DC | Number of Decks [custom] | Features | Contact Finish | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Grayhill Inc. | 6.45 mm | Fixed | Flatted (3.17mm Dia) | 9.53 mm | Panel Mount | 150 mA 200 mA | 45 ° | Non-Shorting (BBM) | 115 V | 18.77 mm | Solder Lug | SP3T | 1 | 28 V | 1 | Process Sealed | Gold | |
Grayhill Inc. | Fixed | Flatted (3.17mm Dia) | 9.53 mm | Panel Mount | 150 mA 200 mA | 45 ° | Non-Shorting (BBM) | 115 V | 18.77 mm | Solder Lug | SP5T | 1 | 28 V | 1 | Gold | 5 | ||
Grayhill Inc. | 6.45 mm | Fixed | Flatted (3.17mm Dia) | 9.53 mm | Panel Mount | 150 mA 200 mA | 45 ° | Non-Shorting (BBM) | 115 V | 18.77 mm | Solder Lug | SP4T | 1 | 28 V | 1 | Process Sealed | Gold | 4 |
 Grayhill Inc. | 6.45 mm | Fixed | Flatted (3.17mm Dia) | 9.53 mm | Panel Mount | 150 mA 200 mA | 45 ° | Non-Shorting (BBM) | 115 V | 18.77 mm | Solder Lug | DP4T | 2 | 28 V | 1 | Process Sealed | Gold | 4 |
