LM3430 Series
Manufacturer: Texas Instruments
Beta
⌘K
IC LED DRIVER CTRLR PWM 12WSON
| Part | Applications | Voltage - Supply (Max) [Max] | Internal Switch(s) | Dimming | Topology | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Type | Mounting Type | Frequency | Supplier Device Package | Voltage - Supply (Min) [Min] | Number of Outputs | Board Type | Current - Output | Frequency - Switching | Outputs and Type | Outputs and Type | Voltage - Output | Utilized IC / Part | Voltage - Input [Min] | Voltage - Input [Max] | Regulator Topology | Main Purpose | Supplied Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Backlight | 40 V | PWM | SEPIC Step-Up (Boost) | -40 °C | 125 ¯C | 12-WFDFN Exposed Pad | DC DC Controller | Surface Mount | 2 MHz | 12-WSON (3x3) | 6 V | 1 | |||||||||||||
 Texas Instruments | Fully Populated | 700 mA | 600 kHz | Non-Isolated | 1 | 48 V | LM3430 | 6 V | 40 V | Boost | DC/DC Step Up | Board(s) |
