APHC Series
Manufacturer: European Thermodynamics Ltd
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
TE HIGH TEMP,CYC,71,4A,SIL
| Part | Height | Size / Dimension Shape | Size / Dimension Width | Size / Dimension Length | Current - Max | Number of Stages | Voltage - Max | Type | Delta Tmax | Resistance |
|---|---|---|---|---|---|---|---|---|---|---|
 European Thermodynamics Ltd | 3.33 mm | Rectangular | 23.5 mm | 28 mm | 3.7 A | 1 | 8.2 V | TEC (Thermoelectric Cooler) | 65 °C | 1.8 Ohm |
 European Thermodynamics Ltd | 3.6 mm | Square | 40 mm | 40 mm | 3.6 A | 1 | 36.1 V | TEC (Thermoelectric Cooler) | 72 °C | 7.7 Ohms |
European Thermodynamics Ltd | 3.63 mm | Rectangular | 30 mm | 34 mm | 3.7 A | 1 | 14.7 V | TEC (Thermoelectric Cooler) | 66 °C | 3.2 Ohms |
European Thermodynamics Ltd | 3.5 mm | Rectangular | 40 mm | 44 mm | 7.4 A | 1 | 14.7 V | TEC (Thermoelectric Cooler) | 66 °C | 1.6 Ohm |
 European Thermodynamics Ltd | 3.1 mm | Rectangular | 36 mm | 54 mm | 19 A | 1 | 7.7 V | TEC (Thermoelectric Cooler) | 58 °C | |
European Thermodynamics Ltd | 3.6 mm | Square | 40 mm | 40 mm | 5.13 A | 1 | 20.1 V | TEC (Thermoelectric Cooler) | 68 °C | 3 Ohm |
European Thermodynamics Ltd | 3.6 mm | Square | 40 mm | 40 mm | 4.53 A | 1 | 20.1 V | TEC (Thermoelectric Cooler) | 69 °C | 3.4 Ohms |
