1571551 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
528-AG11D-ESL-LF=500 DIP,GF/SN
| Part | Termination Post Length | Termination Post Length | Material Flammability Rating | Contact Resistance | Contact Finish Thickness - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Features | Mounting Type | Contact Finish Thickness - Post | Contact Material - Post [custom] | Termination | Housing Material | Number of Positions or Pins (Grid) | Type [custom] | Type [custom] | Type | Contact Finish - Post | Pitch - Post | Pitch - Post | Contact Material - Mating | Pitch - Mating | Pitch - Mating | Contact Finish - Mating | Current Rating (Amps) | Type | Type | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Number of Positions or Pins (Grid) [x] | Number of Positions or Pins (Grid) [y] | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 0.125 in | 3.18 mm | UL94 V-0 | 10 mOhm | Flash | -55 C | 125 °C | Closed Frame | Through Hole | Flash | Nickel | Solder | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 28 | 15.24 mm | 0.6 in | DIP | Gold | 0.1 in | 2.54 mm | Beryllium Copper | 0.1 " | 2.54 mm | Gold | |||||||||
 TE Connectivity AMP Connectors | 0.125 in | 3.18 mm | UL94 V-0 | 10 mOhm | Flash | -55 C | 125 °C | Closed Frame | Through Hole | Flash | Nickel | Solder | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 40 | 15.24 mm | 0.6 in | DIP | Gold | 0.1 in | 2.54 mm | Beryllium Copper | 0.1 " | 2.54 mm | Gold | |||||||||
 TE Connectivity AMP Connectors | 0.125 in | 3.18 mm | UL94 V-0 | 10 mOhm | Flash | -55 C | 125 °C | Closed Frame | Through Hole | Copper Alloy | Solder | Polyester | 20 | DIP | Gold | 0.1 in | 2.54 mm | Copper Alloy | 0.1 " | 2.54 mm | Gold | 3 A | 7.62 mm | 0.3 in | |||||||||
 TE Connectivity AMP Connectors | 0.125 in | 3.18 mm | UL94 V-0 | 10 mOhm | -55 C | 125 °C | Closed Frame | Through Hole | Nickel | Solder | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 20 | DIP | Gold | 0.1 in | 2.54 mm | Beryllium Copper | 0.1 " | 2.54 mm | Gold | 7.62 mm | 0.3 in | 0.63 µm | 25 µin | |||||||||
TE Connectivity AMP Connectors | 0.125 in | 3.18 mm | UL94 V-0 | 10 mOhm | -55 C | 125 °C | Closed Frame | Through Hole | Nickel | Solder | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 8 | DIP | Gold | 0.1 in | 2.54 mm | Beryllium Copper | 0.1 " | 2.54 mm | Gold | 7.62 mm | 0.3 in | 0.63 µm | 25 µin | 2 | 4 | |||||||
TE Connectivity AMP Connectors | 0.125 in | 3.18 mm | UL94 V-0 | 10 mOhm | Flash | -55 C | 125 °C | Closed Frame | Through Hole | Flash | Nickel | Solder | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 16 | DIP | Gold | 0.1 in | 2.54 mm | Beryllium Copper | 0.1 " | 2.54 mm | Gold | 7.62 mm | 0.3 in | 2 | 8 | |||||||
 TE Connectivity AMP Connectors | 0.125 in | 3.18 mm | UL94 V-0 | 10 mOhm | -55 C | 125 °C | Closed Frame | Through Hole | Nickel | Solder | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 18 | DIP | Gold | 0.1 in | 2.54 mm | Beryllium Copper | 0.1 " | 2.54 mm | Gold | 7.62 mm | 0.3 in | 0.63 µm | 25 µin | |||||||||
 TE Connectivity AMP Connectors | 0.125 in | 3.18 mm | UL94 V-0 | 10 mOhm | -55 C | 125 °C | Closed Frame | Through Hole | Nickel | Solder | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 14 | DIP | Gold | 0.1 in | 2.54 mm | Beryllium Copper | 0.1 " | 2.54 mm | Gold | 7.62 mm | 0.3 in | 0.63 µm | 25 µin |
