RJE05166 Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN MOD JACK 6P6C R/A UNSHLD
| Part | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Housing Material | Contact Material | Number of Rows | Number of Positions/Contacts [y] | Number of Positions/Contacts [x] | Tab Direction | Mounting Type | Shielding | Features | Orientation | LED Color | Contact Finish | Connector Type | Termination | Number of Ports |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | 0.152 Ám | 6 Áin | 85 °C | -40 C | Thermoplastic | Phosphor Bronze | 1 | 6 | 6 | Down | Through Hole | Unshielded | Board Lock | 90 ° | Does Not Contain LED | Gold | Jack | Solder | 1 |
 Amphenol ICC (Commercial Products) | 0.76 Ám | 30 Áin | 85 °C | -40 C | Thermoplastic | Phosphor Bronze | 1 | 6 | 6 | Down | Through Hole | Shielded | Board Lock | 90 ° | Does Not Contain LED | Gold | Jack | Solder | 1 |
Amphenol ICC (Commercial Products) | 1.27 µm | 50 µin | 85 °C | -40 C | Thermoplastic | Phosphor Bronze | 1 | 6 | 6 | Down | Through Hole | Shielded | Board Lock | 90 ° | Does Not Contain LED | Gold | Jack | Solder | 1 |
