292251 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER VERT 2POS 2MM
| Part | Features | Contact Type | Contact Shape | Number of Positions Loaded | Insulation Height | Insulation Height | Contact Finish - Post | Termination | Contact Length - Mating | Contact Length - Mating | Material Flammability Rating | Applications | Pitch - Mating [x] | Pitch - Mating [x] | Fastening Type | Insulation Material | Current Rating (Amps) | Voltage Rating | Number of Rows | Mounting Type | Number of Positions | Connector Type | Style | Overall Contact Length | Overall Contact Length | Insulation Color | Shrouding | Contact Material | Contact Length - Post | Contact Length - Post [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Board Guide | Male Pin | Circular | All | 6.8 mm | 0.268 in | Tin | Kinked Pin Solder | 4.2 mm | 0.165 in | UL94 V-0 | General Purpose | 0.079 in | 2 mm | Detent Lock | Polyamide (PA66) Nylon 6/6 | Varies by Wire Gauge | 125 VAC | 1 | Through Hole | 2 | Header | Board to Cable/Wire | 9.09 mm | 0.358 in | Natural | Shrouded - 4 Wall | Brass | 3.2 mm | 0.126 in |
 TE Connectivity Raychem Cable Protection | Board Guide | Male Pin | Circular | All | 6.8 mm | 0.268 in | Tin | Kinked Pin Solder | 4.2 mm | 0.165 in | UL94 V-0 | General Purpose | 0.079 in | 2 mm | Detent Lock | Polyamide (PA66) Nylon 6/6 | Varies by Wire Gauge | 125 VAC | 1 | Through Hole | 8 | Header | Board to Cable/Wire | 9.09 mm | 0.358 in | Natural | Shrouded - 4 Wall | Brass | 3.2 mm | 0.126 in |
TE Connectivity Raychem Cable Protection | Board Guide | Male Pin | Circular | All | 6.8 mm | 0.268 in | Tin | Kinked Pin Solder | 4.2 mm | 0.165 in | UL94 V-0 | General Purpose | 0.079 in | 2 mm | Detent Lock | Polyamide (PA66) Nylon 6/6 | Varies by Wire Gauge | 125 VAC | 1 | Through Hole | 7 | Header | Board to Cable/Wire | 9.09 mm | 0.358 in | Natural | Shrouded - 4 Wall | Brass | 3.2 mm | 0.126 in |
 TE Connectivity Raychem Cable Protection | Board Guide | Male Pin | Circular | All | 6.8 mm | 0.268 in | Tin | Kinked Pin Solder | 4.2 mm | 0.165 in | UL94 V-0 | General Purpose | 0.079 in | 2 mm | Detent Lock | Polyamide (PA66) Nylon 6/6 | Varies by Wire Gauge | 125 VAC | 1 | Through Hole | Header | Board to Cable/Wire | 9.09 mm | 0.358 in | Natural | Shrouded - 4 Wall | Brass | 3.2 mm | 0.126 in |
