G9H-205S Series

Catalog

SSR RELAY SPST-NO 5A 100-240V

Part	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Input [Min]	Voltage - Input [Max]	Mounting Type	Circuit	Output Type	Approval Agency	Voltage - Load [Max]	Voltage - Load [Min]	Load Current	Termination Style
Omron Electronics Inc-EMC Div G9H-205S-DC24	-25 °C	60 °C	19.2 V	28.8 V	Socketable	Hybrid SPST-NO (1 Form A)	AC	CSA UR	240 V	100 V	5 A	Plug In
Omron Electronics Inc-EMC Div G9H-205S DC12	-25 °C	60 °C	9.6 V	14.4 V	Socketable	Hybrid SPST-NO (1 Form A)	AC	CSA UR	240 V	100 V	5 A	Plug In
Omron Electronics Inc-EMC Div G9H-205S DC5	-25 °C	60 °C	4 V	6 V	Socketable	Hybrid SPST-NO (1 Form A)	AC	CSA UR	240 V	100 V	5 A	Plug In
