ALM07FD15 Series
Manufacturer: Amphenol Industrial Operations
Beta
⌘K
CONN RCPT FMALE 19POS GOLD CRIMP
| Part | Insert Material | Applications | Color | Ingress Protection | Shell Material | Current Rating (Amps) | Mounting Feature | Shielding | Orientation | Shell Finish | Primary Material | Contact Finish - Mating | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Shell Size - Insert [Max] [custom] | Shell Size - Insert [Min] [custom] | Material Flammability Rating | Connector Type | Termination | Shell Size - Insert [Max] | Shell Size - Insert [Min] | Shell Size - Insert |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol Industrial Operations | Silicon Rubber | Aviation | Gray | IP67 - Dust Tight Waterproof | Composite | 7.5 A | Bulkhead - Front Side Nut | Shielded | N | Gray Zinc Nickel | Composite | Gold | 125 °C | -65 ░C | 19 | 19 | 15 | UL94 V-0 | Receptacle Female Sockets | Crimp | |||
 Amphenol Industrial Operations | Silicon Rubber | Aviation | Gray | IP67 - Dust Tight Waterproof | Composite | 7.5 A 13 A | Bulkhead - Front Side Nut | Shielded | N | Gray Zinc Nickel | Composite | Gold | 125 °C | -65 ░C | 12 | UL94 V-0 | Receptacle Female Sockets | Crimp | 97 | 15 | |||
 Amphenol Industrial Operations | Silicon Rubber | Aviation | Gray | IP67 - Dust Tight Waterproof | Composite | Bulkhead - Front Side Nut | Shielded | N | Gray Zinc Nickel | Composite | Gold | 125 °C | -65 ░C | 2 | UL94 V-0 | Male Pins Receptacle | Crimp | 15-2 | |||||
 Amphenol Industrial Operations | Silicon Rubber | Aviation | IP67 - Dust Tight Waterproof | Composite | 5 A | Bulkhead - Front Side Nut | Shielded | N | Electroless Nickel | Composite | Gold | 125 °C | -65 ░C | 37 | UL94 V-0 | Male Pins Receptacle | Crimp | 35 | 15 | ||||
 Amphenol Industrial Operations | Silicon Rubber | Aviation | Gray | IP67 - Dust Tight Waterproof | Composite | 5 A | Bulkhead - Front Side Nut | Shielded | N | Gray Zinc Nickel | Composite | Gold | 125 °C | -65 ░C | 37 | UL94 V-0 | Receptacle Female Sockets | Crimp | 35 | 15 | |||
 Amphenol Industrial Operations | Silicon Rubber | Aviation | IP67 - Dust Tight Waterproof | Composite | 7.5 A 13 A | Bulkhead - Front Side Nut | Shielded | N | Electroless Nickel | Composite | Gold | 125 °C | -65 ░C | 12 | UL94 V-0 | Receptacle Female Sockets | Crimp | 97 | 15 |
