845-110 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 110POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Read Out | Contact Material | Contact Type | Mounting Type | Gender | Contact Finish | Color | Termination | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Pitch | Pitch | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Cantilever | Through Hole | Female | Gold | Green | Solder | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 55 | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 110 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Cantilever | Through Hole | Female | Gold | Green | Wire Wrap | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 55 | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 110 | Floating Bobbin Top Mount Opening | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Cantilever | Board Edge Straddle Mount | Female | Gold | Green | Solder | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 55 | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 110 | Card Extender | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Cantilever | Through Hole | Female | Gold | Green | Solder | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 55 | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 110 | Flush Mount Side Opening Unthreaded | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Cantilever | Through Hole | Female | Gold | Green | Solder | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 55 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 110 | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Cantilever | Through Hole | Female | Gold | Green | Wire Wrap | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 55 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 110 | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Cantilever | Through Hole | Female | Gold | Green | Solder | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 55 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 110 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Cantilever | Through Hole | Female | Gold | Green | Wire Wrap | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 55 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 110 | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Cantilever | Through Hole | Female | Gold | Green | Solder | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 55 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 110 | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Cantilever | Through Hole | Female | Gold | Green | Solder | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 55 | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 110 |
