852-80 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN HEADER SMD 70POS 1.27MM
| Part | Number of Positions Loaded | Operating Temperature [Min] | Operating Temperature [Max] | Fastening Type | Contact Material | Mounting Type | Contact Type | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Insulation Material | Voltage Rating | Material Flammability Rating | Connector Type | Number of Positions | Contact Shape | Contact Finish - Post | Insulation Color | Shrouding | Pitch - Mating | Pitch - Mating | Contact Length - Mating | Contact Length - Mating | Number of Rows [custom] | Termination | Row Spacing - Mating | Row Spacing - Mating | Insulation Height | Insulation Height | Contact Length - Post [x] | Contact Length - Post [x] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | All | -55 C | 125 °C | Push-Pull | Brass | Surface Mount | Male Pin | 0.1 in | 2.54 mm | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 150 VDC | UL94 V-0 | Header | 70 | Circular | Tin | Black | Unshrouded | 1.27 mm | 0.05 in | 3 mm | 0.118 in | 2 | Solder | |||||||
Preci-Dip | All | -55 C | 125 °C | Push-Pull | Brass | Surface Mount | Male Pin | 0.1 in | 2.54 mm | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 150 VDC | UL94 V-0 | Header | 50 | Circular | Tin | Black | Unshrouded | 1.27 mm | 0.05 in | 3 mm | 0.118 in | 2 | Solder | |||||||
 Preci-Dip | All | -55 C | 125 °C | Push-Pull | Brass | Surface Mount | Male Pin | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 150 VDC | UL94 V-0 | Header | 38 | Circular | Tin | Black | Unshrouded | 1.27 mm | 0.05 in | 3 mm | 0.118 in | 2 | Solder | 0.05 in | 1.27 mm | |||||||
 Preci-Dip | All | -55 C | 125 °C | Push-Pull | Brass | Right Angle Through Hole | Male Pin | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 150 VDC | UL94 V-0 | Header | 38 | Circular | Tin | Black | Unshrouded | 1.27 mm | 0.05 in | 3 mm | 0.118 in | 2 | Solder | 0.05 in | 1.27 mm | 0.128 in | 3.25 mm | 0.126 " | 3.2 mm | |||
Preci-Dip | All | -55 C | 125 °C | Push-Pull | Brass | Surface Mount | Male Pin | 0.1 in | 2.54 mm | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 150 VDC | UL94 V-0 | Header | 16 | Circular | Tin | Black | Unshrouded | 1.27 mm | 0.05 in | 3 mm | 0.118 in | 2 | Solder | |||||||
 Preci-Dip | All | -55 C | 125 °C | Push-Pull | Brass | Right Angle Through Hole | Male Pin | 0.1 in | 2.54 mm | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 150 VDC | UL94 V-0 | Header | 78 | Circular | Tin | Black | Unshrouded | 1.27 mm | 0.05 in | 3 mm | 0.118 in | 2 | Solder | 0.174 in | 4.42 mm | 0.126 " | 3.2 mm | |||
 Preci-Dip | All | -55 C | 125 °C | Push-Pull | Brass | Surface Mount | Male Pin | 0.1 in | 2.54 mm | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 150 VDC | UL94 V-0 | Header | Circular | Tin | Black | Unshrouded | 1.27 mm | 0.05 in | 3 mm | 0.118 in | 2 | Solder | Pick and Place | |||||||
Preci-Dip | All | -55 C | 125 °C | Push-Pull | Brass | Surface Mount | Male Pin | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 150 VDC | UL94 V-0 | Header | 50 | Circular | Tin | Black | Unshrouded | 1.27 mm | 0.05 in | 3 mm | 0.118 in | 2 | Solder | 0.05 in | 1.27 mm | |||||||
Preci-Dip | All | -55 C | 125 °C | Push-Pull | Brass | Surface Mount | Male Pin | 0.1 in | 2.54 mm | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 150 VDC | UL94 V-0 | Header | 86 | Circular | Tin | Black | Unshrouded | 1.27 mm | 0.05 in | 3 mm | 0.118 in | 2 | Solder | |||||||
Preci-Dip | All | -55 C | 125 °C | Push-Pull | Brass | Surface Mount | Male Pin | 0.1 in | 2.54 mm | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 150 VDC | UL94 V-0 | Header | 6 | Circular | Tin | Black | Unshrouded | 1.27 mm | 0.05 in | 3 mm | 0.118 in | 2 | Solder | Pick and Place |
