M20-875 Series

Catalog

CONNECTOR, HEADER, 8POS, 2.54MM, 2ROW

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Features	Pitch - Mating	Pitch - Mating	Fastening Type	Insulation Material	Number of Positions Loaded	Contact Type	Contact Material	Termination	Insulation Color	Material Flammability Rating	Contact Shape	Shrouding	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Style	Current Rating (Amps)	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Number of Rows [custom]	Connector Type	Contact Finish - Post	Insulation Height	Insulation Height	Number of Positions	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Length - Mating	Contact Length - Mating
Harwin Inc. M20-8750442	2.54 µm	100 µin	Board Guide	0.1 "	2.54 mm	Push-Pull	Glass Filled Nylon 6T Polyamide (PA6T)	All	Male Pin	Brass	Solder	Black	UL94 V-0	Square	Unshrouded	0.1 in	2.54 mm	Board to Board Cable	3 A	Surface Mount	-40 C	105 ░C	2	Header Breakaway	Tin	0.1 in	2.54 mm	8	Gold	Flash	0.228 in	5.8 mm
Harwin Inc. M20-8751042	2.54 µm	100 µin	Board Guide	0.1 "	2.54 mm	Push-Pull	Glass Filled Nylon 6T Polyamide (PA6T)	All	Male Pin	Brass	Solder	Black	UL94 V-0	Square	Unshrouded	0.1 in	2.54 mm	Board to Board Cable	3 A	Surface Mount	-40 C	105 ░C	2	Header Breakaway	Tin	0.1 in	2.54 mm	20	Gold	Flash	0.228 in	5.8 mm
Harwin Inc. M20-8750842R	2.54 µm	100 µin	Board Guide	0.1 "	2.54 mm	Push-Pull	Glass Filled Nylon 6T Polyamide (PA6T)	All	Male Pin	Brass	Solder	Black	UL94 V-0	Square	Unshrouded	0.1 in	2.54 mm	Board to Board Cable	3 A	Surface Mount	-40 C	105 ░C	2	Header Breakaway	Tin	0.1 in	2.54 mm	16	Gold	Flash	0.228 in	5.8 mm
Harwin Inc. M20-8750242	2.54 µm	100 µin	Board Guide	0.1 "	2.54 mm	Push-Pull	Glass Filled Nylon 6T Polyamide (PA6T)	All	Male Pin	Brass	Solder	Black	UL94 V-0	Square	Unshrouded	0.1 in	2.54 mm	Board to Board Cable	3 A	Surface Mount	-40 C	105 ░C	2	Header Breakaway	Tin	0.1 in	2.54 mm	4	Gold	Flash	0.228 in	5.8 mm
Harwin Inc. M20-8750242R	2.54 µm	100 µin	Board Guide	0.1 "	2.54 mm	Push-Pull	Glass Filled Nylon 6T Polyamide (PA6T)	All	Male Pin	Brass	Solder	Black	UL94 V-0	Square	Unshrouded	0.1 in	2.54 mm	Board to Board Cable	3 A	Surface Mount	-40 C	105 ░C	2	Header Breakaway	Tin	0.1 in	2.54 mm	4	Gold	Flash	0.228 in	5.8 mm
Harwin Inc. M20-8750342	2.54 µm	100 µin	Board Guide	0.1 "	2.54 mm	Push-Pull	Glass Filled Nylon 6T Polyamide (PA6T)	All	Male Pin	Brass	Solder	Black	UL94 V-0	Square	Unshrouded	0.1 in	2.54 mm	Board to Board Cable	3 A	Surface Mount	-40 C	105 ░C	2	Header Breakaway	Tin	0.1 in	2.54 mm	6	Gold	Flash	0.228 in	5.8 mm
Harwin Inc. M20-8751042R	2.54 µm	100 µin	Board Guide	0.1 "	2.54 mm	Push-Pull	Glass Filled Nylon 6T Polyamide (PA6T)	All	Male Pin	Brass	Solder	Black	UL94 V-0	Square	Unshrouded	0.1 in	2.54 mm	Board to Board Cable	3 A	Surface Mount	-40 C	105 ░C	2	Header Breakaway	Tin	0.1 in	2.54 mm	20	Gold	Flash	0.228 in	5.8 mm
Harwin Inc. M20-8750542	2.54 µm	100 µin	Board Guide	0.1 "	2.54 mm	Push-Pull	Glass Filled Nylon 6T Polyamide (PA6T)	All	Male Pin	Brass	Solder	Black	UL94 V-0	Square	Unshrouded	0.1 in	2.54 mm	Board to Board Cable	3 A	Surface Mount	-40 C	105 ░C	2	Header Breakaway	Tin	0.1 in	2.54 mm	10	Gold	Flash	0.228 in	5.8 mm
Harwin Inc. M20-8750342R	2.54 µm	100 µin	Board Guide	0.1 "	2.54 mm	Push-Pull	Glass Filled Nylon 6T Polyamide (PA6T)	All	Male Pin	Brass	Solder	Black	UL94 V-0	Square	Unshrouded	0.1 in	2.54 mm	Board to Board Cable	3 A	Surface Mount	-40 C	105 ░C	2	Header Breakaway	Tin	0.1 in	2.54 mm	6	Gold	Flash	0.228 in	5.8 mm
