74HCT139 Series

Catalog

74HC139; 74HCT139 - DUAL 2-TO-4 LINE DECODER/DEMULTIPLEXER@EN-US SOP 16-PIN

Part	Type	Package / Case	Package / Case [x]	Package / Case [y]	Voltage - Supply [Min]	Voltage - Supply [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Circuit	Independent Circuits	Mounting Type	Supplier Device Package	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Voltage Supply Source	Grade	Qualification	Package / Case [custom]	Package / Case [custom]
Freescale Semiconductor - NXP 74HCT139D,653	Decoder/Demultiplexer	16-SOIC	0.154 in	3.9 mm	4.5 V	5.5 V	125 °C	-40 °C	1 x 2:4	2	Surface Mount	16-SO	4 mA	4 mA	Single Supply
Freescale Semiconductor - NXP 74HCT139PW-Q100J	Decoder/Demultiplexer	16-TSSOP	0.173 in	4.4 mm	4.5 V	5.5 V	125 °C	-40 °C	1 x 2:4	2	Surface Mount	16-TSSOP	4 mA	4 mA	Single Supply	Automotive	AEC-Q100
Freescale Semiconductor - NXP 74HCT139DB,112	Decoder/Demultiplexer	16-SSOP			4.5 V	5.5 V	125 °C	-40 °C	1 x 2:4	2	Surface Mount	16-SSOP	4 mA	4 mA	Single Supply			0.209 in	5.3 mm
Freescale Semiconductor - NXP 74HCT139D,652	Decoder/Demultiplexer	16-SOIC	0.154 in	3.9 mm	4.5 V	5.5 V	125 °C	-40 °C	1 x 2:4	2	Surface Mount	16-SO	4 mA	4 mA	Single Supply
